foton auto parts 6x4 dump truck

1)Outer/inner skin is FRP panel

2)polyurethane insulated ,PU foam density 42-45kg/m3
3)304 stainless steel locks ,hinges,door frame, wrap angle

4) aluminium alloy Edge Protector

5)EPDM rubber door seal

6)thickness: 62mm ,82mm,102mm or other special demands, body size as you demanded

7)side door is optional

8)Light in weight: 40% lighter than metal body.

9) Better insulation:  K value less than 0.3w/m2k..

10)High in strength and long life: 5 times longer than metal body.

11)Non-corrosion, non-pollution, anti-brine, acid and soda-resisting.

12)Easy to be assembled and repaired at site.

Our products can be shipped in CBU (completely built up) and CKD (completely knock down) type

Temperature range,-18°C--+25°C,special request reach to -40°C

 The Thickness

1)Front wall panel:85mm

2)Rear wall panel:85mm

3)Side wall panel:85mm

4)Roof wall panel:105mm

5)Floor wall panel:105mm

6)With the dimensions, the truck body can be the best Refrigeration Effect. But we also can change the       Thickness by your requirements. And the thickness range is from 25mm to 150mm

 1. Drive model:4*2,6*2,6*4,8*4; Chassis Brand : Dongfeng, FAW, Auman, Shacman, Sinotruck, North Benz( Bei Ben), etc.

     2. At present Our Truck with Euro 2 and Euro 3 Emission Standard; Engine model: Dongfeng Cummins(140HP-340HP),Yuchai(120HP-310HP),ISUZU(96HP-260HP),etc.

     3. Cab: Flat-head/High-head with one sleeper(optional), comfortable design, rated passengers:3, with air condition; Steering control: Left hand drive /Right hand drive optional;

     4. Length of Cargo body: 10-40inch; Capacity of Cargo body:10-70CBM. The material of the cargo body is opptional according of which kinds of goods the truck transport, with perfect heat preservation, Open model: Read double-open or Side-open.

     5. Equip with the international famous brand such as USA” Carrier”, Korea “ Hanya” un-independent refrigeration units , The temperature of the cargo body inside could be -18°C--25°C, the refrigeration effect is very good.

Yakai Auto is the most unique manufacture of Refrigerated and Insulated Van. The technology and equipments of the production is all introduced from Germany equipment. Based on it we developed “all-close panel, adhesive structure with the type of building block, Freon-free polyurethane vesicant material”.

For the Van Truck production, Yakai Auto is the first to use the special composite materials panel for the dry goods van vehicles in China. Using the Aluminum material and the entire composite panel to create the van body is not overpassed by the other welding, riveting and small plate mosaic approach

Truck body panel kits
FRP/GRP+PU sandwich panel
Thickness: 30-120mm
Size:1.5-12m in length,width and height depends on truck model or customized

Floor: checkered aluminum plate, or pattern 304 steel plate

Door: standard are double rear doors, side door optional

Ceiling lights inside, indicating light on rear and front wall

HIGHIGH QUANLITY ICE CREAM REFRIGERATED BOX TRUCK
