1. 2.5-5 Tons Nissan mini refrigerated van/refrigerated vehicles for ice cream, cheese and vegetables
model |
Box size |
thickness |
Door frame and lock |
20ft/40ft container |
A |
3.3*1.85*1.9 |
62mm |
Stainless steel |
8sets/ 20sets |
|
4.4*2.03*2.11 |
82mm |
Stainless steel |
|
|
4.9*2.21*2.11 |
82mm |
Stainless steel |
|
|
5.4*2.2*2.2m |
102mm |
Stainless steel |
|
|
6.1*2.3*2.3 |
102mm |
Stainless steel |
|
|
6.4*2.42*2.36 |
102mm |
Stainless steel |
|
|
6.72*2.3*2.1 |
102mm |
Stainless steel |
|
|
7.1*2.45*2.39 |
102mm |
Stainless steel |
|
|
8.1*2.5*2.5 |
102mm |
Stainless steel |
|
B |
3.3*1.85*1.9 |
60mm |
Galvanized polishing |
5sets/ 11sets |
|
4.4*2.03*2.11 |
80mm |
galvanized polishing |
|
|
4.9*2.21*2.11 |
80mm |
galvanized polishing |
|
|
6.4*2.42*2.36 |
100mm |
galvanized polishing |
|
|
6.72*2.3*2.1 |
100mm |
galvanized polishing |
|
|
7.1*2.45*2.39 |
100mm |
galvanized polishing |
Truck Body Outer Dimension: |
2450mm(L) x 1800mm(W) x 1200mm(H) |
Truck Body Inner Dimension: |
2310mm(L) x 1660mm(W) x 1060mm(H) |
Front Penal Thickness: |
70mm |
Floor Penal Thickness: |
83mm |
Roof Penal Thickness: |
70mm |
Side Penal Thickness: |
70mm |
Rear Penal Thickness: |
70mm |
Side Door |
Yes; 1 Set; |
Side Door Dimension |
810mm(W) x 1013mm(H) |
Rear Door |
Yes; |
Rear Door Dimension |
Full Size Double Opening |
Refrigeration Unit Type |
Optional |
Refrigeration Unit Optional Type |
Kingtec K125, Mitsubishi TD17DX |
Refrigeration Unit Service Ladder |
None |
Refrigeration Unit Service Platform |
None |
Multi-Temperature System |
None |
Multi-Temperature Clapboard Type |
None |
Cargo Bar |
None |
Flooring Type |
Anti-Sliding/Alumimum Checkered Plate |
Meat Hanging System |
None |
Meat Hanging Hooks Type |
None |
Meat Hanging Hooks Quantity |
None |
Meat Hanging Rail Type |
None |
Meat Hanging Rail Quantity |
None |
Ceiling Light Quantity |
1 Set of LED |
Mark Light Quantity |
Yes; 2 x White LED; 2 x Red LED |
Lock Set Type |
Stainless Steel |
Hinges Type |
Stainless Steel |
Aluminum Decoration Profiles |
Yes; Anodized Aluminum Extrusion Profile |
PVC Strip Curtain |
Yes |
If you need more material, product picture,more detail specification & functions, please
send us inquiry directly, we will provide the best service for you in short time!
Refrigerated trucks used to transport frozen or fresh goods closed Frontal compartment is fitted with a refrigeration unit cooling device and polyurethane insulation for refrigerated transport vehicles, commonly used in the transport of refrigerated food (refrigerated trucks), dairy products(milk truck), fruits and vegetables (fresh produce truck), vaccines, medicines (vaccines truck).
Refrigerator: Carrier, ThermoKing, Changyu,Yuda, Kelly, or as requested SpecificationsRefrigerated Vehicle Body; excellent in heat insulating performance; FRP sheets as surface and PU as core; Sizes as per you.
for truck body,we are transport it by container.
for light truck,we are transport it by container. nude packing
for bigger truck,RO-RO ship it. nude packing frigo box for truck
3 tons 4x2 isuzu mini van truck, refrigerated truck for s
Equipment: chassis, the heat preservation box body--standard material is glass fiber reinforced plastic, 8mm polyurethane insulation layer, Standard back open door and refrigeration unit;
Optional: polyurethane material, color steel plate, stainless steel, etc, 5mm insulation layer, side open door;
Function: transport frozen foods (ice truck), dairy (milk truck) fruits and vegetables (fresh transporter) vaccine and drug transporter (vaccine truck) Fridge freezer fiberglass truck box/25 ton dump truck body/cold van/cold box truck CKD truck body panel/Fecho furgao/25 ton dump truck body/refrigerated truck box for fish freezer truck body CKD truck body panel/Fecho furgao/25 ton dump truck body/refrigerated truck box for fish 25 ton dump truck bodies truck body panel/Fecho furgao/25 ton dump truck body/refrigerated truck box for fish , etc
1.Famous chassis isuzu refrigerated truck,isuzu mini van truck
2.Good performance isuzu refrigerated truck,isuzu mini van truck
3.Factory price isuzu refrigerated truck,isuzu mini van truck
4.Fully past ISO &3C isuzu refrigerated certificate,isuzu mini van truck .
5.5 tons mini refrigerated truck, refrigerator freezer truck
