frp insulated panel aluminum foil composite

Vehicle model

King kong598

fuel type

diesel

Emission Standard

Euro I

Cabin model

King row,tiltable/1780mm

Whole Vehicle
main dimensions

Overall dimensions (L×W×H)mm

6050×2150×2510

Inner dimensions of the cargo body (L×W×H)mm

3800×2000×800

Driving type

4x2

Wheel base (mm)

3400

tread  (front/rear) (mm)

1567/1584

Weight data

Curb weight(kg)

4590

Rated payload(kg)

11200

Gross vehicle weight(kg)

15985

Max payload(kg)

14000

 seating capacity

3

Whole vehicle
main performance

Max. speed (km/h)

≥75

Max. slope of climb (%)

≥30

Min.turning diameter(m)

≤7

Engine

Model

YZ4102QF

Type

Four-cylinder, in-line,water cooling,direct injection(DI) type, with turbo charger.

Displacement(L)

3.857

Rated power(kw/rpm)

70.6/2800

Fuel consumption(L/100km)(only for reference)

15

Gear box

Model

17D45F1

Speed ratio

Highgear:I1:7.312,I2:4.311,I3:2.450,I4:1.534,I5:1.000.IR:7.661

Lowgear:I1:12.825,I2"7.561,I3:4.297,I4:2.690,I5:1.754,IR:13.437

Rear axle

Type/Final gear ratio

1092/6.833

Steering gear

Type

Mechanical recirculating ball type

Steering Wheel

left/right hand drive

LHD

Brake system

Service brake

Dual circuits pneumatic brake

Parking brake

Air cut valve

Auxiliary brake

Exhaust brake

Wheels and tyre size

6+1/8.25-20

Electric device

Rated voltage

24V
