Insulated Thickness: 70mm
Width of Sub-frame: 748mm
Left front side door + retractable steps
3 LED Interior Lights
Rear divided door + strip curtains
Aluminum checkered flooring
Air tubes not exceeding 25mm in thickness to run horizontally and not vertically
Single E' track
Scuff plate (running across the front,rear and at both sides at 152mm above flooring
Front LED AMBER lights (24v)
Front side corner LED lights (24v)
AMBER LED lights in middle of body
Rear side corner RED LED lights (24v)
2 rear lights (24v.) facing backwards LED RED
Rear bumper
Rear fenders + mud flaps
4 drain valves (fitted to each corner of floor) to facilitate condensation
1 grab handle fitted at left side at rear door frame to assist in exiting + entering body
Outside panels to be FRP
| SIZE | Load in 40'HQ |
| 2200*1600*1600mm | 54 |
| 26 | |
| 3300*1900*1900mm | 36 |
| 15 | |
| 3400*1900*1900mm | 36 |
| 15 | |
| 4350*2000*2000mm | 25 |
| 12 | |
| 4950*2100*2000mm | 20 |
| 8 |
Note: 1. The material of the truck body are color coated steel sheet . 2. The truck bodies are with stainless steel door frame and locks.
Note: Before fixing, make sure the parts are available.
Step 1. Fixing the side swage and front swage on the motherboard with bolts or jointing.
Step 2. Fixing the stand aluminum swages on the front boarding with nails, then put into front swage on the motherboard.
Step 3. Fixing the side boarding put into the side swages, then put the side aluminum swages into side boarding.
Step 4. put the top boarding into the side swages till suitable position.
Step.5 fixing the corner aluminum with nails on two front corners. Be sure the suitable position.
Step6. put the rear door on top boarding and side boarding; put the top steel swage on the rear door's swage; fixup the rear door with nails on two sides and top. Fixup the bottom of the rear door with bolts & nuts.
Step 7. Waterproof be putted into all the apertures on the box.
Our main products are refrigerated truck and body, dry truck and box,dump truck and body,foton truck.
We choose the best product to the customer.
We are looking for long term cooperation with customer. Therefore, if there is any quality feedback, we shall provide technical support and after sales service promptly. Easy to wear off parts list for each model is available upon customer's request. Service parts shall be sent along with each complete truck as well to ensure easy maintenance and service of each truck.
In the past 15 years, we only do a truck, we are more professional.
nude packing
