Specifications
1>Turntables for trailers & tractors2>Size: 400-1300mm
3>Material: Steel, QT500-7
4>High quality, Competitive price
Xiamen Tinmy Autoparts can supply different types and sizes of Turntables
1. JOST & BPW type
2. Size: 400mm-1300mm, Any size is available
3. Certificate: ISO9001:2000/TS16949
4. Type: Casting Turntable /Single Ring, Double Ring
5. Material: Steel, QT500-7
6. High quality, competitive price, fast delivery
Item No. | A | B | E | F | H | Weight | Ring Thickness | Ball Dia. |
mm | mm | mm | mm | mm | kg | mm | ||
TMTD650-B01 | 650 | 665 | 552 | 510 | 80 | 74 | 14 | 16/19 |
TMTD880-B01 | 880 | 895 | 780 | 740 | 80 | 80 | 14 | 16/19 |
TMTD1096-B01 | 1096 | 1110 | 990 | 950 | 80 | 100 | 14 | 16/22 |
TMTD1000-B01 | 988 | 1000 | 870 | 830 | 92 | 88 | 14 | 16/19 |
TMTD1100-B01 | 1095 | 1108 | 975 | 940 | 92 | 100 | 15 | 16/22 |
TMTD1200-B01 | 1195 | 1208 | 1076 | 1040 | 92 | 118 | 15 | 16/22 |
TMTD1200-B02 | 1198 | 1215 | 1075 | 1040 | 92 | 120 | 16 | 16/22 |
Item No. | A | B | E | F | H | Weight | Ring Thickness | Ball Dia. |
mm | mm | mm | mm | mm | kg | mm | ||
TMTS500-D01 | 500 | 437 | 379 | 310 | 52 | 25 | 10 | 16 |
TMTS650-D01 | 650 | 587 | 523 | 465 | 52 | 32 | 10 | 16 |
TMTS750-D01 | 750 | 687 | 620 | 565 | 52 | 36 | 10 | 16 |
TMTS850-D01 | 850 | 787 | 723 | 665 | 52 | 41 | 10 | 16 |
TMTS950-D01 | 950 | 888 | 820 | 752 | 56 | 45 | 12 | 16 |
TMTS950-D02 | 952 | 885 | 821 | 750 | 60 | 48 | 12 | 20 |
TMTS1050-D01 | 1050 | 987 | 923 | 865 | 52 | 53 | 12 | 16 |
TMTS1100-D01 | 1102 | 1027 | 923 | 854 | 56 | 61 | 12 | 20 |
Plastic Ribbon, Pallet in seaworthy packing
Sample service, Customized Service is available
