Home > Consumer Electronics > Audio & Sets > Professional Audio > Trailer Turntable

Trailer Turntable

Name: Trailer Turntable
Brand: TINMY
SKU: 141211398
Availability: InStock

US$ 35 - 180 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

TINMY

Model Number:

TMTS1100-A01

Contact Supplier Request Quote Chat Now

Xiamen Tinmy Autoparts Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen Xingang

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name TINMY

Model Number TMTS1100-A01

Specifications

Trailer Turntable:
1>400-1300mm turntable
2>Certi: ISO/TS16949
3>turntables for trailers & tractors
4>Material:QT500-7

Trailer turntable:

Item No.	A	B	E	F	H	Weight	Ring Thickness	Ball Dia.
Item No.	mm	mm	mm	mm	mm	kg	mm	Ball Dia.
TMTS500-A01	500	500	392	376	55	32	10	16
TMTS685-A01	685	700	590	565	80	45	13	16
TMTS880-A01	880	895	779	754	80	60	13	16
TMTS1000-A01	1000	1015	885	860	80	76	14	22
TMTS1000-A02	1022	1013	879	856	90	85	14	22
TMTS1000-A03	1000	1015	885	860	90	84	14	22
TMTS1100-A01	1100	1115	985	960	90	98	15	22
TMTS1100-A02	1100	1111	983	949	90	98	15	22
TMTS1200-A01	1200	1211	1083	1050	90	110	15	22
TMTS1300-A01	1300	1315	1180	1146	90	118	16	22
TMTS1300-A02	1300	1315	1185	1160	90	118	16	22

Item No.	A	B	E	F	H	Weight	Ring Thickness	Ball Dia.
Item No.	mm	mm	mm	mm	mm	kg	mm	Ball Dia.
TMTD650-B01	650	665	552	510	80	74	14	16/19
TMTD880-B01	880	895	780	740	80	80	14	16/19
TMTD1096-B01	1096	1110	990	950	80	100	14	16/22
TMTD1000-B01	988	1000	870	830	92	88	14	16/19
TMTD1100-B01	1095	1108	975	940	92	100	15	16/22
TMTD1200-B01	1195	1208	1076	1040	92	118	15	16/22
TMTD1200-B02	1198	1215	1075	1040	92	120	16	16/22

Item No.	A	B	E	F	H	Weight	Ring Thickness	Ball Dia.
Item No.	mm	mm	mm	mm	mm	kg	mm	Ball Dia.
TMTS500-D01	500	437	379	310	52	25	10	16
TMTS650-D01	650	587	523	465	52	32	10	16
TMTS750-D01	750	687	620	565	52	36	10	16
TMTS850-D01	850	787	723	665	52	41	10	16
TMTS950-D01	950	888	820	752	56	45	12	16
TMTS950-D02	952	885	821	750	60	48	12	20
TMTS1050-D01	1050	987	923	865	52	53	12	16
TMTS1100-D01	1102	1027	923	854	56	61	12	20

Tinmy Turntable factory can supply different turntables for semi-trailers, full trailers and tractors.

The Size from 400-1300 slewing rings with JOST TYPE AND BPW TYPE.

We have forging turntables and Casting turn table

1>.Size:400-1300, Any size is available
2>.Certificate: ISO/TS16949
3>. Turntables for trailers & tractors
4>. Delivery: Within two weeks after receive TT deposit payment or LC.

5>. Material: Steel QT500-7

6>.High quality with competitive price.

Xiamen Tinmy Co., Ltd, which belongs to Xiamen Tinmy Inc., Is a leading supplier in auto parts and construction machine parts that organized by several factories and joint-ventured manufacturers and is successfully certified with TS16949 and ISO9001/2000 quality control system. With more then ten years' development, our construction machine department can supply a full range of spare parts for undercarriage spare parts and bucket and so on . Our main spare parts are track roller,top roller,sprocket,track link ,bolt & nut, bucket ,teeth ,adaptor,muffler etc .
