Isolated truck body,CKD truck body panels, cargo box

FOB Price

USD $300 - $1,500 / Unit

1 Unit(Min.Order)

Supply Ability 10000 Unit / Units per Month
Port Qingdao
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Type:	Other, Truck Panel	Truck Model:	Other, All kinds of Trucks	Size:	as request
Material:	as request, PU,Steel,Aluminium	OEM No.:	S	Place of Origin:	Shandong, China
Brand Name:	Xier	Model Number:	ZZT

Product Description

Specifications

Isolated truck body,
CKD truck body panels, cargo box
1. Light-weight &high-intensity
2. fire resistant & insulation

1.The advanatages of Isolated truck body,CKD truck body panels, cargo box

Light-weight &high-intensity 2.fire resistant & insulation 3.anti-impact&scratch

Features:

1.light weight and high strength.

The whole panel is light weight and high strength.It can lighten the whole product's weight without reducing the strength.

2. heat & sound insulation

The panel has excellent heat and sound insulation performance.So it can be used in where temperature is required.

3.mold &mildew resistance

The surface of the board----Keying Glasbord,makes it resistant to mold and mildew ,and easy to clean.It is also resistant to scratches,abrasions,staining.

4.Environmental protection

There is non-toxic,non-radiomaterial,and tasteless,no harmful fumes.

5.Easy to install

It can be cut freely into all kinds of irregular plates.

-----------------------------------------------------------------------------------------------------------------------------------

Correlation Parameter:

Table 1 Physical Property

Test Item	Test Method	Unit	Result
Barcol hardness	GB/T3854-2005	Hba	53
Tensile strength	GB/T4944-2005	MPa	42.1
Elongation at break	GB/T1040.1-2006 and	%	1.6
Tensile modulus	GB/T1040.2-2006	MPa	4590
Flexural strength	GB/T9341-2008	MPa	129.6
Flexural modulus	GB/T9341-2008	MPa	4964
Taber abrasion	GB/T5478-2008	mg	20.3
Specific gravity	GB/T1463-2005		1.600
Impact resistance	GB/T14153-93	J	0.42
Absolute water absorption	GB/T1462-2005	g	0.05

Table 2 Surface Sterilization Performances

Test Item	Test Method	Unit	Result
Aureus Removal rate	GB15979-2002	%	70
Coli Removal rate	GB15979-2002	%	84
Salmonella Removal rate	GB15979-2002	%	74
Shigella Removal rate	GB15979-2002	%	75

Table 3 Toxic substances content

Test Item	Test Method	Unit	Technical Requirements	Result
Volatile matter content	GB18586-2001	g/m²	≤75	4.2
Heavy Metal Soluble Lead	GB18586-2001	mg/m²	≤20	1.7
Heavy Metal Soluble Cadmium	GB18586-2001	mg/m²	≤20	0.25

---------------------------------------------------------------------------------------------------------------------------

2.Products of our company: CKD van truck body/

Truck body from FRP honeycomb panel/Keying Glasbord(frp panel)+PP honeycomb+Glasbord(frp panel)

We can supply: refrigerated truck body, insulated truck body, dry cargo truck body, plateform truck body, explosion-proof truck body, dump truck body,tank truck body, wing opening truck body, catering truck body, any other special purpose truck and truck body.....etc

The refrigerated truck body proecessed with FRP with insulation foam. Our standard thickiness is 80mm. But the thickness can be change according to customer's requirements.

Stainless steel door frame and door lock system.

---------------------------------------------------------------------------------------------------------------------------

3.The main character of our truck body:

Light in weight, better insulation, high in strength and long useful life.

Non-corrosion ,non-pollution,anti-brine,acid and soda-resisting.

Easy to be asembled and repaired at site.

---------------------------------------------------------------------------------------------------------------------------
