Help CenterFAW Refrigerated Unit Truck
Related Products
Specifications
1).low fuel consumption refrigerator truck2).High safety design frozen truck
3).Temperature:-18-20
4). ISO9001-2000 truck
1.The advantage of refrigerator truck
1).Cooling effect
2).Energy saving
3).Driving Comfort
4).High safety design
5).capacity:7tons- 10 tons
6).temperature:-18-20
7). High efficient and comfortable ergonomic space
8).Technical equipment leading in market
2.The Specifications of Refrigerator freezer truck for
MODEL
ZZT5250XLC
CHASSIS
ID NO.
CA1251P1K2L7T3EA80/ 1241928
category
manufacturer
FAW JIEFANG Qingdao Auto Factory
axle
3
wheel basemm)
1900+5650
wheel track(front/rear mm)
1942/1847
tire size
10.00-20,10.00R20,11.00-20,11.00R20
tire
8
ENGINE
model
CA6DF3-22E3
manufacturer
Faw Jiefang Automobile Co., Ltd. WUXI Diesel Engine Branch
delivery capacity(ml)
6740
fuel
diesel
rated power(Kw)
171
emission standard
GB3847-2005,GB17691-2005EUR
FRAME
FRONT
type
steel plate spring
quantity
12/12
BACK
type
steel plate spring
quantity
10+9
CAR LOAD
dimension parameters
overall dimensions(mm)
11990 2540 3960
L*W*H
interior cargo body
9350 2310 2400
L*W*H
cubage(m3)
52
front overhang/rear overhang(mm)
1375/3065
quality parameters
approach angle/departure angle(°)
18/12
curb weight(Kg)
11640
rated payload(Kg)
13165
gross vehicle weight(Kg)
25000
max. speed(km/h)
90
Persons in cab (persons)
3
3.Sale points of Foton refrigerator truck
1).high quality
2).low price
3).best configuration
4).low fuel consumption
5).excellent performance
6).high speed
7).heavy load capacity
8).advanced skills
4.Products of Our Company
We can supply: refrigerated truck body, insulated truck body, dry cargo truck body, plateform truck body, explosion-proof truck body, dump truck body,tank truck body, wing opening truck body, catering truck body, any other special purpose truck and truck body.....etc.
Refrigerated truck body, Refrigerated truck body panels, CKD REFRIGERATED TRUCK BODY PANEL, Freezer truck body, van
Refrigerated truck body, refrigerated truck body panel, CKD refrigerated truck body, FRP refrigerated truck body, truck body
Truck body, FRP truck body, FRP refrigerated truck body, FRP Cargo box, FRP truck box, FRP insulated truck body, reefer van body,
reefer truck body, Truck body panels, CKD truck body, Freezer truck body, isolation truck body, Isolated cargo box, truck box, truck van body, Van truck body, cargo van body, meat transport truck body, truck cold box, truck cool box, REFRIGERATED TRUCK BODY ckd
