Specifications
Our Mini Refrigerated Truck are high quality,low price with nice apperance. engine's power is great. power steering,The Specifications of Refrigerator freezer Trucks ZZT 5045XLC
| Model | ZZT5045XLC | ||
| CHASSIS | Model and ID NO. | BJ1046V9JD5-S | |
| Category | |||
| Manufacturer | Jiefang Automobile Co., LTD | ||
| Axle | 2 | ||
| Wheelbase(mm) | 2800 | ||
| Wheel Track(Front/Rear mm) | 1415,1510 | ||
| Tyre Size | 6.50R15,6.50-16,6.50R16 | ||
| Tyre | 6 | ||
| ENGINE | Model | 4D22E 4D26 4DW93-84E3 4DW83B-79E3 | |
| Manufacturer | Anhui Quanchai Motor Co., LTD, | ||
| Delivery Capacity(ml) | 2156 2596 2540 2155 | ||
| Fuel | Diesel | ||
| Rated Power(Kw) | 65 68 67 58 | ||
| Emission Standard |
| ||
| FRAME | Front | Type | Steel Plate Spring |
| Quantity | 7 | ||
| Rear | Type | Steel Plate Spring | |
| Quantity |
| ||
| CAR LOAD | Dimension Parameters | Overall Dimensions(mm) | 5490*1940,1990*2910 |
| L*W*H | |||
| Interior Cargo Body Dimentions(mm) | 3570*1770*1760 | ||
| L*W*H | |||
| Cubage(m3) | |||
| Front Overhang/Rear Overhang(mm) | 1090/1600 | ||
| Quality Parameters | Approch Angle/Departure Angle | 23/ 20 | |
| Curb Weight(Kg) | 2730 | ||
| Rated Payload(Kg) | 1635,1570 | ||
| Gross Vehicle Weight(Kg) | 4495 | ||
| Max. Speed(km/h) | |||
| Person In Cab(Persons) | 3 | ||
Sale points of Foton refrigerator truck
1).high quality
2).low price
3).best configuration
4).low fuel consumption
5).excellent performance
6).high speed
7).heavy load capacity
8).advanced skills
Main Products
We manufacture: Refrigerated Truck( refrigerator van), Insulated Truck (Isolated Truck,Isolated Van, Insulated Van), Dry Cargo Truck (Cargo Van, Box Truck), Light Truck, Explosion-proof Truck, Dump Truck, Store-stake Truck, Truck Crane, Medical Wast Vehicle Truck, Wing Opening Truck, Catering Truck, Mobile Stage Truck, Mobile Shop, Box Trailer, Catering Trailer, Truck body (Van Body), Refrigerated Truck Body, Insulated Truck Body, Trailer, Semi-trailer, any other special purpose vehicles and vehicle bodies ect.
Truck Body:
Truck body, Truck van body, Truck box, CKD Trucks body panel, Cargo box, Van body, Meat Transport truck body, Cargo body, Van box
We manufacture truck bodies as your request, material can be: FRP, Aluminium, Color coated steel, ect. The bodies of trucks are the most popular sandwich type, which can be more strong and beautiful.
