Help CenterFAW 8 T Foton Crane Truck
Related Products
Specifications
Foton cargo crane truck 4*22.max lifting moment 420kNm
ing radius 15
4.lifting capacity:8t
Euro 3 standard
FOTON Crane Truck
cargo crane truck 6*4
2.max lifting moment 420kNm
ing radius 17.6
4.lifting capacity 8 t
Euro 3 standard
---------------------------------------------------------------------------------------------------------------------------------------------
1. The synchronous telescopic boom of steel cable type makes higher efficency and lifting capacity.
2. The planet lifting can reduces the temperture of the hydraulic system efficently, have a faster lifting speed and high reliability.
3. The seperation controlling system is more saft and convenient.
4. You can chose to fit the rear leg or not.
5. Can refitted by the chassis like: FAW, DONGFENG, AUMAN, AND ISUZU ect.
---------------------------------------------------------------------------------------------------------------------------------------------
Crane truck , Truck with crane , truck mounted crane. Hoist crane truck cargo
----------------------------------------------------------------------------------------------------------------------------
------------------------
| Model | ZZT5140JSQ (183) | ||
| CHASSIS | Model and ID NO. | CA1140PK2L3EA801225212 | |
| Category | |||
| Manufacturer | FAW Jiefang Qingdao Auto Factory | ||
| Axle | 2 | ||
| Wheelbase(mm) | 4970 | ||
| Wheel Track(Front/Rear mm) | 18001800 | ||
| Tyre Size | 9.00-20,10.00-20,9.00R20,10.00R20 | ||
| Tyre | |||
| ENGINE | Model | BF4M1013-18E3BF4M1013-16E3CA6DE3-18E3CA6DF3-18E3 | |
| Manufacturer | China FAW Group Co., LTDFaw Jiefang Automotive Co., LTD Wuxi Diesel Engine Works(The Last Engine Model) | ||
| Delivery Capacity(ml) | 4764476466186740 | ||
| Fuel | Diesel | ||
| Rated Power(Kw) | 143124143143 | ||
| Emission Standard | GB3847-2005,GB17691-2005 | ||
| FRAME | Front | Type | Steel Plate Spring |
| Quantity | 10 | ||
| Rear | Type | Steel Plate Spring | |
| Quantity | 12+8 | ||
| CAR LOAD | Dimension Parameters | Overall Dimensions(mm) | 9000*2498*3470 |
| L*W*H | |||
| Interior Cargo Body Dimentions(mm) | 5400*2320*600 | ||
| L*W*H | |||
| Cubage(m3) | 1312/2718 | ||
| Front Overhang/Rear Overhang(mm) | 22/18 | ||
| Quality Parameters | Curb Weight(Kg) | 8990 | |
| Rated Payload(Kg) | 4815 | ||
| Gross Vehicle Weight(Kg) | 14000 | ||
| Person In Cab(Person) | 3 | ||
| Max. Speed(km/h) | 90 | ||
| Remark | Telescopic Boom Crane:Model:SQ6.3,Crane Weight:3200kg,Max. Lifting Capacity: 6300kg | ||
--------------------------------------------------------------------------------------------------------------------------------------------
1. The synchronous telescopic boom of steel cable type makes higher efficency and lifting capacity.
2. The planet lifting can reduces the temperture of the hydraulic system efficently, have a faster lifting speed and high reliability.
3. The seperation controlling system is more saft and convenient.
4. You can chose to fit the rear leg or not.
5. Can refitted by the chassis like: FAW, DONGFENG, AUMAN, AND ISUZU ect.
