Help CenterDongfeng 4x2 Chassis Road Sweeper Truck/ Off Road Truck//Suction Sweeping Vehicles
Related Products
-
Dongfeng Chassis Garbage Truck/Compressed Garbage Truck/ Refuse Collector Truck 3000-6000LUS$ 10,000 - 30,000MOQ: 1 Set -
High Pressure Washing Truck / Vacuum Sewage Tanker TrailerUS$ 10,000 - 30,000MOQ: 1 Set
-
Dongfeng Chassis 4x2 Hydraulic Arm Compactor Mini Garbage Trucks for SaleUS$ 10,000 - 30,000MOQ: 1 Set
-
High Pressure Vacuum Sewage Tanker Truck/trailerUS$ 10,000 - 30,000MOQ: 1 Set
-
High Pressure Washing Vacuum Sewage Suction Truck TankerUS$ 10,000 - 30,000MOQ: 1 Set
The main technical parameters of Road sweeping truck | |||
Product Name | 5Ton Road sweeping truck | ||
Transmission Model | Manual | Emission standards | Euro 3 |
Total Mass(kg) | 14490 | Overall dimensions(L*W*H)(mm) | 7650×2480×3200 |
Rated Payload(kg) | 6800 | Max speed(Km/h) | 85 |
Curb Weight(kg) | 7495 | Approach/Departure angle (°) | 25/20 |
Chassis | Chassis Model | EQ1110GLJ | |
Wheel base(mm) | 4500 | ||
Tire specification(mm) | 10.00-20 | ||
Front tread | 1940 | ||
Rear tread | 1860 | ||
Fuel Type | Diesel | ||
Horse Power(hp) | 185 | ||
Chassis Supplier | Dongfeng Automobile Co., Ltd. | ||
Number of tires | 6 | ||
Drive Wheel | 4*2 | ||
Cab | one and a half row cab, whole metal- enclosed | ||
Engine parameters | Engine Model | ISDe185 30 | |
ISDe210 30 | |||
Exhaust | 6700 | ||
Engine Power(ml/kw) | 136 | ||
Engine Manufacturer | Guangxi Yuchai Machinery Co., Ltd. | ||
Vehicle Description | According to the Chassis to choose the Cab. Protection material:Q235 Carbon steel. Connections: Left and right side shields exemption. The rear underrun protection is the use of welded connections . The rear protective section size is 100×50×5 mm | ||
Section | |||
Special Function | a. The work efficiency, The same work area can reduce the time greatly. Cleaning costs, To be sure that the cleaning of the machine unit area's cost is lower than the manual. b. Machinery can be avoided cleaners do not use the average, the cleaning effect is not uniform . c. Road sweeper to avoid some of the traffic accident. | ||
Vehicle Remarks | 1 Regular checks of the hydraulic system oil spill . | ||
2 Regular checks of hydraulic stock on a regular basis to the various moving parts of the filling oil. | |||
3 Smear lubricant at the surface of each rail. | |||
If you have any other questions, interests, or you need to customerize the trailers by design, pls CONTACTWITH
Ms Branda for details:
Tel/whats App/Viber/Wechat
0086 15908932191
QQ: 28723108
Skype: plytrailer500
