Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar

Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar thumbnail-1
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar thumbnail-2
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar thumbnail-3
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar thumbnail-4
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar thumbnail-5
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar thumbnail-6
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar photo-1
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar photo-2
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar photo-3
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar photo-4
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar photo-5
Small Box Tipper Tractor Truck Hydraulic Trailer Dumper With Drawbar photo-6
US$ 6,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Full Trailer
Material:
Steel
Certification:
Other, CCC/ISO/DOT/CE/SGS
Contact Supplier Request Quote Chat Now
Qingdao Phillaya International Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Full Trailer
Material Steel
Certification Other, CCC/ISO/DOT/CE/SGS
Size As the buyer's request
OEM No. 3708322800116
Max Payload 60T
Place of Origin Shandong, China
Brand Name PHILLAYA
Model Number PLYDSTLDDXXX
Product Description
3 Axles 50 Tons Drawbar Dump Trailer
Rated Capacity
Axle
Tire
Overall Dimension
20-40Tons
2PCS
8PCS
6500*2500*3300mm
50-60Tons
3PCS
12PCS
10500*2500*3300mm
70-90Tons
4PCS
16PCS
12000*2500*3500mm
Wheelbase
6810+1310+1310mm
Axle Tonnage
13Tons,16Tons,20Tons Optional
Tyre Model
8.25R20/10.00R20/11.00R20/12.00R25
Suspension
Mechanic/Air Bag/Independent Type Optional
Brake System
Dual Lines Braking System With Automatic Air Chambers,Four double and two single chamber
Material
Q345B manganese plates,automatic submerged arc
Box Thickness
Bottom Wall:6-12mm     Side Wall:4-8mm
Electric System
24V, 7core socket, lights according to European standards.
Kingpin
2' Or 3.5'(50# Or 90# Optional)
Spare Tyre Carrier
One Unit
Tool Box
1 box of standard tools
Color/Logo
As Required
Detailed Images

Bottom Chassis

Q345-B carbon steel with automatic submerged arc.The main beams and side beams are H type steel with factory standard size.And cross beams are the channel steel,quantity is customized on the techinical basis.
The warranty for the bottom chassis if life-time.

Box Body

Q345-B carbon steel with automatic submerged arc.
The shape of the box is rectangle and U-type optional.

The size of the box is customized,and the thickness of the bottom plate/side palte depends on the material to transport.

Hydraulic Cylinders

The hydraulic system normally includes the Pneumatic control valve,power takeoff,shaft pumps, pumps, pneumatic distribution valves, hydraulic cylinders, lifting brackets, hydraulic lines.

Trailer Testing

All the trailers will be function tested before leaving our factory to assure every part can work well.

Packing & Delivery
ONE
By Containers(20ft,40ft,45ft)
For the normal trailers, if the overall dimension is within 11800*2500*1550mm,we can load it innto the container;
And for the tanker type trailers,if the tank volume is within the 40CBM/40000Liters,we also can choose to transport by this way to save the shipping cost.
TWO
By Bulk Ship/Ro-Ro Ship
If the overall dimension of the trailers oversize the containers,we can choose to transport by bulk sjip/ro-ro ship,which the shipping cost is based on the overall cubmeters of the trailers.
Three
By Road/Train
If the delivery term is DAF XXX border,we can choose pull the trailer by the tractor or transport by the train to the border.
Certifications
Our Service

Pre-Sale /After-Sale Service

* Professional Sales Guide

* Customerized Design from Engineer

* Production Feedback on each Step for Quality Control

* Efficient Freight Agency for Shipment

& Destination Custom Aid


* 1 Year Gurantee on Main Parts

* Mainbeam Lifetime Promise

* 24H Open Hotline for After Sales

Our Company
PHILLAYA INTERNATIONAL

Exporting department of Phillaya Special Vehicle Group Co., LTD, a joint venture of 4 factories , majored different trailer aspects, with the Professional Experience more than 15 years, Certified by the Chinese Government Manufacture, Majored in Semi Trailer, Special Vehicle manufacture, Our Products are Mainly Exported to Philippine, Bangladesh, Thailand, Myanmar, Vietnam, Nigeria, Russia, Mongolia, Congo, Kenya, Tanzania, etc... More than 30 Countries.
