Axle NO |
3 |
Rated Load (kg) |
40T |
Wheel Base (mm) |
1310 |
Outside Dimension |
8000X2480X1580 L×W×H (mm) |
Tyre specifications |
385/65r22.5 |
Tyre No |
6 |
leaf-spring Pcs |
10 |
Axle |
13 T |
Suspension |
Leaf-spring rigid suspension |
Main Beam Material |
Q345B manganese plates, automatic submerged arc welded |
Brake System |
Dual line braking system with automatic braking system/chambers |
Brake Air Chamber |
6pcs |
Platform |
4 mm diamond steel plate |
Brake System |
Dual Lines Braking System With Automatic Air Chambers |
Brake Air Chamber |
Four double and two single chamber |
Electrical System |
24V, 7core socket, lights according to European standards. |
Tool Box |
1 box of standard tools |
Spare tire carrier |
2 sets |
Color and Logo |
Depends on the buyer’s requirement. |
Other Specifications |
The frame can be flat plate style and skeleton style.Twist lock settings installed 12 only, 8 only,and 4 only to satisfy the containers with different sizes for convince. |
Phillaya international trading Co., Ltd, a special vehicle manufacture
with the professional experience more than 15 years, certified by the Chinese government manufacture,majored in manufacturing all kinds of semi trailers and special vehicle.
Phi-lla-ya,as the company name in chinese,our products' main market is Africa,South
America and Asia,so far, our products are exported to Philippine, Bangladesh, Thailand, Myanmar, Vietnam, Nigeria, Russia, Mongolia, Congo, Kenya, Tanzania, etc...More than
20 countries.
1. Send us inquiries or contact us on-line on your desired product / model
through our contact information.
2. We shall reply you within 2 hours.
3. Negotiations on your needed configuration.
4. Configuration on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. Manufacturig process updated news.
9. Production completement.
10. Shipment
11. Custom Clearance
12. A/S service for 1 year.
