Sitong 3 axles stake bulk semi trailer 40t 60t livestock trailer for agricultural product
Stiong Trailer offers a wide range of CARGO TRAILER which is used for carrying dry cargo loads. These Cargo Trailer can carry different kind of standard dry cargo loads, pallets, bulk bag cements according to demand.
Stake semi trailer generally has a flat bled enclosed by fence-like exterior,also called livestock semi trailers,semi livestock trailer,livestock tractor trailer, It is widely used to transport animals, steel coils, coals, and other light puffy cargoes.
The fence-like structure and bodywork of our semi trailer are properly designed to suit the kind of goods to be transported. In design of this stake bed trailer, we take special care to reduce its weight while ensuring the load capacity is up to the standard. The simplified design allows easy disassembly. It also reduces production costs, thus passing on more savings to customers.
Vertical beam is either straight, or arch-shaped that looks like a gooseneck. The I-beam has a web that measures 450mm to 500mm in height. Submerged arc welding method is used to connect the vertical beam to the base structure. The chassis is sandblasted to receive a smooth finish.
|
https://youtu.be/oZ1qBXoltDw?list=PLiyf8lirC34AEzepUl49uIjz4NV9gK6Qp |
Specification:
Weight: | |
Tare Weight |
8000kg-14000kg |
Loading Capacity |
30T-90T |
Axle Weight Load |
13T-16T |
Specification: | |
Axle number |
3 |
Axle Brand |
Fuwa/BPW/Optional upon choice |
Suspension |
Common mechanical |
King Pin |
2" or 3.5" traction pin |
Dimensions (LxWxH) |
12400~18000×2500~3200×1500+1800mm |
Thickness of box |
3mm |
Support legs |
28T |
Wheel Rim |
8.5-20,9.0-20,8.28-22.5,9.0-22.5 steel wheel rim / optional upon choice |
Wheelbase |
7180/6680/6260+1310+1310mm |
Steel Spring |
10-13 pieces per axle |
Landing Gear |
Manual operating, Heavy duty landing gear (Brand Optional upon choice) |
Floor |
3-5 Diamond steel plate |
Accessories |
1 Set standard tool box |
Light |
Tail lamp with turn signal, brake light & reflector, side lamp etc. |
Painting |
1coat of anticorrosive prime, twice coats of final paint |
Tire: | |
Tire spec. |
12R22.5 Vacuum tire/11.00R20 steel wire tire |
Number of Tire |
8 or 12 or 16 pieces |
Spare Tire Carriers |
2 pieces |
Frame: (specs. and materials) | |
Main beam |
The height of the beam is500-550mm; Upper plate:14-18mm;Down plate is 16-20mm;Middle plate is 8-12mm. |
Brake: | |
Brake brand |
Optional upon choice |
Brake Chamber |
Six big chamber( Brand Optional upon choice ) |
Brake system |
Dual Line Brake system (ABS Optional upon choice) |
Product details:
Production Process:
Workshop:
Sitong Trailer Factory
Founded in 2002, more than 14 years experience in production and export,with strong technical support and dependably after-sales service.
Located in Liangshan, Shandong Province(Trailer production base of China) and covers an area of more than 35000 square meters,we enjoy convenient access to major transportation networks,with more than 150 people and 20 technicians including 5 professor senior engineer and 12 senior technicians,all our products are manufactured with advanced equipment and strict QC procedures in order to ensure high quality.Meanwhile,OEM and ODM orders are welcome.
Description of products
Tanker Trailer / Low Bed Trailer / Flatbed Trailer / Dump Trailer / Container Transport Trailer / Side Wall Semi Trailer / Fence Semi Trailer / Box semi trailer etc.
About R&D
Sitong Trailer has a team of passionate and experience R&D engineers.Most of them possess advanced degrees and rich experiences.The managements are also specialists and experts with an average of over 10 years experience.These individuals are the ones who developed the core intellectual property of the company.This is the technical foundation of the expertise that make Sitong a industry leader.
About Qality Control
As a leading semi trailer manufacturer,Sitong is delicated to quality control by ensuring quality in every step of the manufacturing prcess.Our quality assurance management includes:
1.A set of detailed procedures that covers all manufacturing processes.
2.Monitoring processes to ensure their effectiveness.
3.Keeping adequate records.
4.Checking output for defects,with appropriate corrective action wherever necessary.
5.Regular review of individual processes and the quality system itself for effectiveness.
6.Facilitating continuous improvement.
