Home > Products > New Products > LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor
LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor
- 100000 Piece / Pieces per Month
- Shanghai / Ningbo
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | YUMO | Model Number: | LJ1A-24B |
Usage: | Position Sensor | Theory: | Optical Sensor | Output: | Analog Sensor |
Product Description
LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor
YUMO type | ||||
Detection distance: 8mm+_10% | ||||
Non-fluse | DC | NPN | NO | LJ1A-24 |
NC | LJ1A-24B | |||
AC | Two-wire | NO | LJ1A-220 | |
NC | LJ1A-220B | |||
Product Features: | ||||
Output Current | DC | 200mA | ||
SCR/Relay | 300mA | |||
Output voltage | DC(NPN,PNP) type 3V under ,Two-wire:3.9V under ,AC 10V under | |||
Current consumption | DC (NPN,PNP) type DC 12V- 8mA,24V-15mA,AC 10mA under | |||
Standard sensing object | 18×18×1(A3 Iron) | |||
Frequency response | 400Hz/25Hz | |||
Working temperature | -25℃ ~+75℃ | |||
Insulation resistance | 50MΩ | |||
Housing Material | ABS Resin | |||
Protection class | IP67 |
L LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor LJ1A-24B DC NC NPN Non fluse IP67 Detection distance 8mm Integrated Proximity Switches Transistor Sensor sensor parking sensor temperature sensor pressure sensor oxygen sensor speed sensor motion sensor position sensor water level sensor sensor light level sensor air flow sensor sensor temperature fuel sensor ultrasonic sensor proximity sensor fuel level sensor pt100 temperature sensor water sensor pir sensor tire pressure sensor flow sensor oil pressure sensor humidity sensor infrared sensor weight sensor water tank level sensor car sensor pt100 sensor air pressure sensor wireless motion sensor hidden camera capacitive sensor led sensor light digital temperature sensor air velocity sensor lambda sensor water flow sensor sensor switch fuel tank level sensor soil moisture sensor piezoelectric sensor ultrasonic level sensor gas sensor car parking sensor infrared sensor price ir sensor pm2.5 sensor ultrasonic sensor price price list of electronic sensor spo2 sensor fuel pressure sensor mini bluetooth motion sensor tpms sensor light sensor motion sensor bracelets photoelectric sensor motion sensor led lights x-ray sensor dental digital sensor faucet automatic door sensor oil sensor photocell sensor water temperature sensor water pressure sensor small motion sensor infrared sensor smart phone torque sensor magnetic sensor proximity sensor cost vibration sensor 12v motion sensor throttle position sensor liquid level sensor current sensor motion detection sensor laser distance sensor body temperature sensor sensor map sensor led motion sensor light ph sensor microwave sensor wireless reverse camera and parking sensor urinal sensor distance sensor wireless temperature sensor motion sensor light switch water detection sensor oil level sensor tilt sensor automatic sensor glass sliding door seat occupancy sensor laser sensor auto sensor proximity sensor bluetooth solar motion sensor light steering angle sensor car parking sensor system inductive sensor motion sensor led recessed light metal detector sensor ultrasonic sensor distance 10 meter fingerprint sensor pir sensor price motion sensor light with camera wind speed sensor ultrasonic fuel level sensor reversing sensor human detector sensor underwater ultrasonic sensor sensor tap pressure sensor cost laser motion sensor rain sensor capacitive level sensor light sensor switch rpm sensor pir sensor module micro motion sensor heart rate sensor flex sensor hall sensor wifi door sensor bosch oxygen sensor automatic door open close sensor pressure sensor pad sensor lamp inductive proximity sensor long range ultrasonic sensor water hardness sensor door sensor electromagnetic parking sensor vibration sensor price accelerator pedal sensor clothes sensor air conditioner temperature sensor dissolved oxygen sensor sensor dustbin sensor pedometer manual light sensor price photo sensor conductivity sensor force sensor optic sensor k type thermocouple temperature sensor parking lot sensor system temperature and humidity sensor microwave motion sensor module moisture sensor ccd sensor beam sensor wind sensor boiler water level sensor seismic sensor mini motion sensor accelerometer sensor ultrasonic water level sensor solar sensor light o2 sensor led light with sensor crankshaft sensor gps fuel level sensor wireless temperature sensor 433mhz ozone sensor sensor measuring body temperature carbon dioxide sensor voc sensor sensor water tap steering sensor dental x-ray sensor fingerprint sensor price door sensor lock infrared temperature sensor camera with temperature sensor pulse sensor motion sensor faucet piezoelectric pressure sensor nellcor spo2 sensor thermal image sensor omron sensor 12 volt motion sensor light automatic sliding door sensor sliding door sensor price camshaft position sensor weight sensor for trucks cmos sensor 12v motion sensor switch led motion sensor ceiling light load sensor smoke sensor microwave motion sensor z wave sensor ph sensor price gyro sensor car blind spot sensor proximity sensor proximity sensor cost proximity sensor bluetooth inductive proximity sensor 5v proximity sensor capacitive proximity sensor car proximity sensor alarm with proximity sensor door proximity sensor magnetic proximity sensor 12v proximity sensor proximity sensor for lg nexus 4 optical proximity sensor infrared proximity sensor analog inductive proximity sensor ultrasonic proximity sensor door proximity sensor lock proximity sensor waterproof ir proximity sensor truck proximity sensor
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
