YUMO Din Rail MDR-20 din rail power supply Switching power supply
Specifications:
1. CE ROHS approved
2. 220V input
3. 81% efficiency
4.2 years warranty
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d. 2 years warrenty ,buy with confidence
YUMO Din Rail MDR-20 din rail power supply Switching power supply YUMO Din Rail MDR-20 din rail power supply Switching power supply YUMO Din Rail MDR-20 din rail power supply Switching power supply
Features |
Universal AC input/Full range |
Installed on DIN railTS35/7.5 or 15 |
Protection:Short circuit/Overload/Overvoltage |
No load power consumption0.75W |
LED indicator for power on |
DC OK signal Output(20W) |
DC OK relay contact(40-60W) |
Cooling by free air convection |
100% full load burn-in |
1 years warranty |
AC input voltage range88-264VAC 120-370DC |
AC inrush currentCold start,20A at 115VAC,40A at 230VAC |
DC adjustment range±10 rated output voltage, |
Overload protecton105-160,constant current limiting,auto-recovery |
Over voltage protection110-135,rated output voltage. |
Setup,rise,hold up time100ms,30ms,100ms at full load and 230VAC |
Withstand voltage:I/P-O/P:3KVAC,I/P-FG:1.5KVAC,1minute |
Working temperature-20-50 100 70 50 |
DC OK signalOpen collector |
DC OK relay contact(40-60W) |
Safety standardsUL508,TUVEN60950-1. |
EMC standardsEN55022D class B,EN61000-3-2,EN61000-4-2,3,4,5,6,8,11,ENV50204 |
Connection I/P:3 poles,O/P:3 poles screw DIN terminal |
DimensionL*W*Hmm 22.5*90*100 |
Model |
Output |
Tolerance Voltage |
Ripple and noise |
Efficiency |
MDR-20-5 |
5V, 0-3A |
±2 |
80mvp-p |
76 |
MDR-20-12 |
12V, 0-1.67A |
±1 |
120mvp-p |
80 |
MDR-20-15 |
15V, 0-1.34A |
±1 |
120mvp-p |
81 |
MDR-20-24 |
24V, 0-1.0A |
±1 |
150mvp-p |
84 |
