S-35-24 constant voltage 35W 24V 1.5A Switching Power Supply
35W 24V 1.5A Switching Power Supply S-35-24
| MODEL | S-35-24 | |
| OUTPUT | DC VOLTAGE | 24V |
| RATED CURRENT | 1.5A | |
| CURRENT RANGE | 0 ~ 1.5A | |
| RATED POWER | 36W | |
| RIPPLE & NOISE (max.) Note.2 | 100mVp-p | |
| VOLTAGE ADJ. RANGE | 22.6 ~ 26.4V | |
| VOLTAGE TOLERANCE Note.3 | ±1.0% | |
| LINE REGULATION | ±0.5% | |
| LOAD REGULATION | ±0.5% | |
| SETUP, RISE, HOLD TIME | 200ms, 100ms, 30ms at full load | |
| INPUT | VOLTAGE RANGE | 85 ~ 132VAC / 170 ~ 264VAC selected by switch 240 ~ 370VDC |
| FREQUENCY RANGE | 47 ~ 63Hz | |
| EFFICIENCY (Typ.) | 78% | |
| AC CURRENT | 0.8A/115VAC 0.45A/230VAC | |
| INRUSH CURRENT (max.) | COLD START 18A/115VAC 36A/230VAC | |
| LEAKAGE CURRENT | <2mA / 240VAC | |
| PROTECTION | OVERLOAD | 105 ~ 150% rated output power |
| Protection type: Fold back current limiting, recovers automatically after fault condition is removed. | ||
| ENVIRONMENT | WORKING TEMP. | -10 ~ +60ºC |
| WORKING HUMIDITY | 20 ~ 90% RH non-condensing | |
| STORAGE TEMP., HUMIDITY | -20 ~ +85ºC, 10 ~ 95% RH | |
| TEMP. COEFFICIENT | ±0.03%/ºC (0 ~ 50ºC) | |
| VIBRATION | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes | |
| SAFETY & EMC | SAFETY STANDARDS | Design refer to UL1012 |
| WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | |
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC | |
| EMI CONDUCTION & RADIATION | Design refer to FCC Part15 J Conduction Class B | |
| OTHERS | MTBF | 435.2K hrs min. MIL-HDBK-217F(25ºC) |
| DIMENSION | 129*98*38mm (L*W*H) | |
| PACKING | 0.37Kg; 45pcs/18.63Kg/0.0326CMB | |
| NOTE | 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance: includes set up tolerance, line regulation and load regulation. |
|
