Limit Switch Hot Sale LXK3-20S B LXK3 Series

Yueqing Yings Import & Export Co., Ltd.
Limit Switch Hot Sale LXK3-20S B LXK3 Series thumbnail-1
Limit Switch Hot Sale LXK3-20S B LXK3 Series photo-1
US$ 30 - 50 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YUMO
Model Number:
LXK3-20S B
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YUMO
Model Number LXK3-20S B
Usage Other, Limit switch
Theory Other, Limit switch
Output Other, Limit switch

Specifications

LXK3-20S B LXK3 Series limit switch hot sale
1.enjoy good reputation in the world
2.in stock
3.easy to use
4.moderate price



Product Description



APPLICATION
      The product is to serve at such control circuit as AC50-60Hz, voltage of 380V AC or 220V DC and current of 10A to automatically control machine tool, limit movement and action of drive mechanism and control program.
      The normal working conditions include an ambient temperature of -25 ~ + 40 , an ambient relative humidity of 90%, an altitude of 2000m and protection degree ofIP65.It complies with the standard of IEC337-1 and GB14048.5-93 and is certified CCC with number of 20020103005130.
Main technology data
Usage
The typical usage of travel switch is to control electrical roagnet of AC or DC
Control capacity
AC-15
DC-15
Rated working voltage
Rated working current
Rated working voltage
Rated working current
380V
0.8A
220V
0.15A
220V
1.4A
110V
0.3A
110V
2.8A

Rated value
Rated insulation voltage Ui-380V,conventional enclosed heating current kh2 -10A
Protection for short-circuit
Rated fuse current 100ARL1-15/10
Operation frequency
AC 2400 times per hour, DC 1200 times per hour
Electrical Life
Electrical life of AC one million and half times, DC three hundred of thousand times
Mechanical Life
Lxk3-20S.H/H1,H2,H3,LXK3-20 S.H/W for 6 million,others for 10 million.
Repetition precision of action
The difference between the maximum(or the minimum)and the mistake no more than 0.05 min in ten times of actions.
Protection degree of enclosure
IP65GB4208-84
Vibration resistance
Frequency:10-55Hz, Acceleration: 10g ( 90M /S),Swing: 0.75mm .

Code name for protection enclosure mode
Type
Action travel
Difference travel
Full travel
Action force
Resilience
Max operation force
Relief force
LXK3-20S H/Z
1.75 -2mm
≤ 1.2mm
≥ 6mm
1± 0.15kg
≥ 0.5kg
3kg

LXK3-20S H/L
LXK3-20S H/B
18° 22°
≤15°
≥60°
1.53± 0.35kg Cro
0.6kg Cro
2.4kg Cro

LXK3-20S
H/T

LXK3-20S H/J
LXK3-20S H/D

1± 0.25kg Cro
0.3kg Cro
2.2kg Cro

LXK3-20S H/H1
70° 80°
40° 60°
90° 5°
2± 0.3kg Cro

2± 0.3kg Cro
LXK3-20S H/H2
LXK3-20S H/H3
LXK3-20S H/W
12° 20°
8°±2°

0.38± 0.08kg Cro
0.15kg Cro







 limit switch hot sale LXK3-20S B LXK3 Serieslimit switch hot sale LXK3-20S B LXK3 Series

limit switch hot sale LXK3-20S B LXK3 Serieslimit switch hot sale LXK3-20S B LXK3 Series





About order

YUMO MEANING:
A global quality electric organization
In order to obtain the highest quality all of
Products according to international standard IEC60898, IEC947-2

YUMO VISION:
To be an enterprise lasting 150 years and beyond
To be an enterprise with a sales network all over 200 countries in the world.
To be the cooperative partner of General Electric

YUMO MISSION:
Better product, better service.

YUMO BUSINESS PRINCIPLE
Cooperation, Sharing, Win-win

YUMO WORKING PRINCIPLE
Enjoy the work, enjoy the life.







Conditions and terms

1. All of the products are brand new, top quality components, absolutely no used items

2 .The pictures are for reference only. Exact specifications should be obtained from the datasheet.

3. Prices, specifications, and availability of all items are subject to change without notice.

 Payment Terms

1.We accept payments made by Western Union, TT, PayPal, L/C

2.Since you made the payment successfully, you can send us the Reference NO or MTCN.

Shipping

1. We will ship the items within 3-15 working days after the payment is reached.

2. We ship to you by Express, by sea, by air according to the PI.

3. Any import fees or charges are the buyer's responsibility.

 Warranty

 Warranty is available based on the following points:

1. Quality guaranteed for one year.

2. If the item you purchase from our company are not of perfected quality, that is they don't work electronically to manufacturers specifications, simply return them to us for replacement or refund.

3. If the items is defective, please notify us within 3 days of delivery.

4. Any items must be returned in their original condition to qualify for a refund or replacement.

Contact Us:

YUEQING YING'S IMPORT & EXPORT CO.,LTD

ADD:ROOM 601,NO.126 LIUYANG ROAD,CHAOYANG VILLAGE,LIUSHI TOWN,YUEQING CITY,

ZHEJIANG PROVINCE, 325604 CHINA

TEL: 0086-577-62791815  FAX: 0086-577-62791825Mobile:0086-13757779011

Skype: benjaminying  Trade Manager: yncync
