Specifications
The SRH Series uses multiplecontact point technology, allowing
for low contact electric resistance
between brushes and ring.
SRH050120-12S Slip ring 12rings 2a per ring
Slip rings can be used in any
electromechanical system requiring
unrestrained, continuous rotation,
while transmitting power and/or
data from a stationary to a rotating
structure.
A slip ring is sometimes referred
to as a rotary electrical interface,
collector, swivel or rotary joint.
The SRH Series uses multiple
contact point technology, allowing
for low contact electric resistance
between brushes and ring. This
reduces electrical noise and the slip ring gets a longer lifetime.
We can also offer custom designs. As a
customer you have the possibility to specify
the slip ring to comply with your needs. We can
also offer hybrid units, for example a combined
slip ring and fiber optic rotary joint, integrated
into one small housing.
Electric data
| Number of Rings | 6, 12, 18, 24, 36, 48, 60, 72 |
| Voltage | 600 VAC |
| Cables/Current rating | tin plated, PTFE insulation /15 A or 10 A: AWG16 2 A: AWG26 |
| Dielectric strength | 1000 VAC at 60 Hz |
| Insulation resistance | 500 VAC at 60 Hz |
| Insulation resistance | > 1000 MΩ / 500 Vcc |
| Nominal speed | 0~1200rpm |
| Temperature | -40°C to +80°C |
| Rating life | depending on speed and on environmental conditions |
| Contact | Gold on Gold / Silver on Silver |
| Protection | IP51~ IP65 |
| We can also offer custom designs. As a customer you have the possibility to specify the slip ring to comply with your needs. | |
The life of the slip ring is decided by the rotating speed, working environment and temperature.
Manufacture slip ring according to customers request, we also welcome OEM to join us.
Important Information about slip ring Conditions
1. All of the slip ring are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The slip ring are guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
