Specifications
ISM8060-002-100B-5L-4 Manual encoder DC5V
*installation place dimension 72 mm, ultra-thin lightweight design, metal
Panel, strong anti-interference ability;
* suitable for NC manual pulse input, NC machine tools, such as line board printing
Brush mechanical zero corrected and signal division.
Electrical parameters of the wave
The output waveform of A and B two phase
Or less consumption current 100 ma
Response frequency 0 ~ 20 KHZ
Empty than 0.5 T - 0.1 T
The phase difference of 90 ° plus or minus 45 °
Power supply voltage, the DC5-12 v DC 5 v, 12 to 24 v DC, DC 5 to 24 v
High level output voltage VH acuity 85% Vcc, low-level VL is 0.3 V or less
Pulse number 25, 100
Circuit characteristics of complementary, E, F - C - open collector - voltage, L - the long drive
* * * mechanical parameters
Position signal four
Maximum speed 500 RPM
Starting torque x10 1-2 nm (+ 25 °C)
Maximum axial load radial 20 n;The axial 10 n
Shock of 980 m/S2, 6 ms, XYZ direction by two times
Shock resistant to 50 m/S2, 10-200 hz, XYZ direction every 2 h
Working life MTBF acuity 10000 h (2000 RPM) + 25 °C,
The weight is about 0.2 Kg
* * * environment parameter
Working temperature
No condensation 30-85%
Storage temperature
- 30 °C to 85 °C
Working temperature
- 10 °C to 70 °C
Protecting waterproof, prevent oil, dustproof IP54
About order
Important Information about Encoder Conditions
1. All of the encoder are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The encoder guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
