Place of Origin Zhejiang, China
Brand Name YUMO
Model Number IHU4808-001G-2000BZ1-2P5L
Usage Speed Sensor
Theory Optical Sensor
Output Switching Transducer

Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder



Product Description



Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder



 1.FEATURES of IHU4808 UVW Rotary Encoder For Servo Motor :


-   Adapt to the spring connect with the electrical ended, suit to the servo motor.
-   External diameter 48*42mm, the fixture mouth is 9*15mm, (the taper is 1: 10) side the aerial socket entry.
-   It has the UVW signal of the test AC motor position.

-   Signals: ABZ, A-B-Z-, UVW, U-V-W-
-   DC 5 V TTL output
-   Impulse per revolution: 1000, 1024, 2048, 2000, 2500 are optional.





2.Technical specification

Property project Specific parameter
Out wave & duty ratio square wave & 0.5T±0.1T
Current Consumption ≤160mA
Response frequency 0-120KHz
Max.permissible revolution 6000rpm
Moment of inertia 4.0*10-6Kg.m2
Starting torque 2.5*10-3Nm
Shaft loading Radical:20N / Thrust :10N
IP rating IP54
Operate & Stock temperature -30C-100C / -25C-80C
Ambient humidity 30-85%(with no condensation)
Power supply DC+5V±5% / +5-12V / +12-24V
Shock resistance 980m/s2,6ms,2 times each in X,Y,Z directions
Vibration resistance 50m/s2,10-200Hz,2 times each in X,Y,Z directions
Operating life MTBF≥30000h (+25C,2000rpm)
Output voltage Vh≥85% Vcc,Vi≤0.3V
Weight 0.15kg



 Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor EncoderHollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor EncoderHollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder

Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor EncoderHollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder



Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder

Hollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor EncoderHollow Shaft Rotary Encoder,Optical Inremental Rotary Encoder, Manual Encoder, Stepper Motor Encoder
