Home > Electrical & Electronics > Switch > Pressure Switch > YM10 Air Compressor Pressure Switch

YM10 Air Compressor Pressure Switch

Name: YM10 Air Compressor Pressure Switch
Brand: YUMO air pressure switch
SKU: 141203410
Availability: InStock

YM10 Air Compressor Pressure Switch thumbnail-1

YM10 Air Compressor Pressure Switch thumbnail-2

YM10 Air Compressor Pressure Switch photo-1

YM10 Air Compressor Pressure Switch photo-2

US$ 1 - 20 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

YUMO air pressure switch

Model Number:

YM10 air pressure switch

Contact Supplier Request Quote Chat Now

Yueqing Yings Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai / Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name YUMO air pressure switch

Model Number YM10 air pressure switch

Max. Current 26A, 26A

Max. Voltage 250V, 250VAC

Max. Working Pressure 75psi

YM10 air/water Pressure Switch for air compressor and tank

Product Description

The YM10 pressure switches are used to regulate the tank pressure between two preset values on small (up to 175psi) electrically driven air compressors. They are available with an unloader valve, which prevents compressors from starting under load, and an auto-off disconnect lever for manual cut off the compressor. A four port manifold style is available which provides a means for easy mounting of valves and gauges.

MODEL	Min ON (Cut-In) PSI	Max Off	Differential	Factory Setting PSI	Electrical Rating		Pipe Fittings	Contact Arrangement
MODEL	Min ON (Cut-In) PSI	(Cut-Out) PSI	PSI	Factory Setting PSI	120VAC	240VAC	Pipe Fittings	Contact Arrangement
YM10-1H1	25	100	20-30	50-80	20A	12A	NPT 1/4 Male or Female NPT	NC
YM10-1H2	35	150	30-40	85-115	20A	12A	1/4" Male or Female NPT	NC
YM10-1H3	50	175	35-55	110-150	20A	12A	1/4" Male or Female NPT	NC
YM10-4H1	25	100	20-30	50-80	20A	12A	1/4" Female NPT (4 Port)	NC
YM10-4H2	35	150	30-40	85-115	20A	12A	1/4" Female NPT (4 Port)	NC
YM10-4H3	50	175	35-55	110-150	20A	12A	1/4" Female NPT (4 Port)	NC
MODEL	Min ON (Cut-In) PSI	Max Off	Differential PSI	Factory Setting PSI	Electrical Rating		Pipe Fittings	Contact Arrangement
MODEL	Min ON (Cut-In) PSI	(Cut-Out) PSI	Differential PSI	Factory Setting PSI	120VAC	240VAC	Pipe Fittings	Contact Arrangement
YM10A-1H1	25	100	20-30	50-80	26A	26A	NPT 1/4 Male or Female NPT	NC
YM10A-1H2	35	150	30-40	85-115	26A	26A	1/4" Male or Female NPT	NC
YM10A-1H3	50	175	35-55	110-150	26A	26A	1/4" Male or Female NPT	NC
YM10A-1H4	70	200	40-55	130-175	26A	26A	1/4" Male or Female NPT	NC
YM10A-4H1	25	100	20-30	50-80	26A	26A	1/4" Female NPT (4 Port)	NC
YM10A-4H2	35	150	30-40	85-115	26A	26A	1/4" Female NPT (4 Port)	NC
YM10A-4H3	50	175	35-55	110-150	26A	26A	1/4" Female NPT (4 Port)	NC
YM10A-4H4	70	200	40-55	130-175	26A	26A	1/4" Female NPT (4 Port)	NC

Approval: UL, CSA, TUV CE, CCC

G1/4 (BSP 1/4) Male or Female Pipe Fittings are available.
