JPJ23F5C2-30BarG YUMO 12VDC Pressure transmitter air pump compressor pressure switch
Detailed introduction to Pressure Transmitter:
Pressure X'mitter/X'ducer
P51(General Purpose)Description
The MediaSensor (P51) family of bulk micro-machined,absolute, gage and sealed pressure transducers and transmitters are for both harsh and benign media with the superior typical accuracy of ±0.5% overall full scale at room temperature and ±0.5~1 % overall full scale over -20°C to 85°C.
Features
Chemical Compatibilities
Any gas or liquid compatible with 304L & 316L Stainless Steel.For example, Motor Oil,Diesel, Hydraulic fluid, brake fluid, water, waste water, Hydrogen, Nitrogen, and Air.
Typical Applications
Refrigeration;Fuel Cells; Pumps; Hydraulics;Process Control;Spraying Systems; Pneumatics; Compressors; Flow; Robotics; Agriculture; Hydrogen Storage.
Temperature Range : -20°C to 85°C
Pressure Range & Accuracy
Pressure Range |
-20°C ~85°C |
25°C(room temp) |
2.1barG~7barG |
+/- 1% FS |
+/- 0.5% FS |
7.1barS~99barS |
+/- 0.5% FS |
+/- 0.5% FS |
99.1barS~350barS |
+/- 1% FS |
+/- 1% FS |
3.1barA~100barA |
+/- 1% FS |
+/- 0.5% FS |
100.1barA~351barA |
+/- 1% FS |
+/- 1% FS |
Specifications
| Output Type | 0.5 ~ 4.5V |
4 ~ 20mA |
1 ~ 5V |
0.1~5V |
0~10V |
Zero Pressure Offset |
0.5V |
4 mA |
1V |
0.1V |
0V |
Full Scale Output |
4.5V |
20 mA |
5V |
5V |
10V |
Operating Temperature |
-20°C ~ 85°C |
-20°C ~ 85°C |
-20°C ~ 85°C |
-20°C ~ 85°C |
-20°C ~ 85°C |
Burst Pressure |
15000psi |
15000psi |
15000psi |
15000psi |
15000psi |
Burst Pressure |
3 X FS |
3 X FS |
3 X FS |
3 X FS |
3 X FS |
Supply Voltage(DC) |
5V |
11 ~ 30V |
11 ~ 30V |
11 ~ 30V |
11 ~ 30V |
Photos of the product:
JPJ23F5C2-30BarG YUMO 12VDC Pressure transmitter air pump compressor pressure switch JPJ23F5C2-30BarG YUMO 12VDC Pressure transmitter air pump compressor pressure switch JPJ23F5C2-30BarG YUMO 12VDC Pressure transmitter air pump compressor pressure switch
