AF-10MR-E PLC controller industrial electric automation control Programmable Logic Controller led Controller
PLC Wifi AF-10MR-E PLC
| Code | Description |
| AF-10MR-E | DC12/24V, 6 points DC input 4 points relay output |
| This model is a DC/AC power supply, with digital input, 6 points AC/DC input, 4 points relay output | ||||
| Exquisite and compact design PLC --Programmable Intelligent Logic Controller (AF-10MR-E) | ||||
| Multi-functional, easy operating, convenient, easy learning | ||||
| Operation temperature -20-70 | Timers 127 | |||
| Storage/Transportation -40-70 | Counters 127 | |||
ProtectionIP20 |
Function blocks : 127 | |||
| Interference Regulation: EN55011(B Class) | RTC time intervals127 |
|||
RTC accuracy: MAX ±5S/day |
Storage capacity64K |
|||
CertificateCE |
Insulation Intensity: IEC1131 |
|||
| Installation: Use a standard DIN rail or screw for installation | Dimensions90*71*58Unitmm |
|||
| Power supply | ||||
Rated voltageAC14-20V/DC12/24V |
Main voltage operation rangeAC12-24V/DC10-28V |
|||
(Output full-load)Typical 3W |
AC/DC24V consumption Typical 125mA |
|||
| Digital input | ||||
| Signal 0DC 0-5V | Input current<0.2mA |
|||
| Signal 1AC12-24V/DC 10-24V | Input current<1mA | |||
Digital output |
||||
Output type: Relay output |
Wiring insulation: Yes |
|||
Points per set1 |
Continuous current max valueMAX 10A |
|||
| Switch frequency | ||||
| Mechanism 10Hz | Resistor load 2Hz |
|||
|
Inductive load 0.5Hz
PLC --Programmable Intelligent Logic Controller (AF-10MR-E) |
||||
AF-10MR-E PLC controller industrial electric automation control Programmable Logic Controller led Controller AF-10MR-E PLC controller industrial electric automation control Programmable Logic Controller led Controller AF-10MR-E PLC controller industrial electric automation control Programmable Logic Controller led Controller
1. Reply inquiry in 24 hours.
2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
3. Answer your question detailed.
4. Solved the problem with you during using our products.
5. Samples will be offered to you for our future cooperation.
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
