Hokuyo UTM-30LN Scanning Laser Rangefinder (30m)
The Hokuyo UTM-30LN Scanning Laser Rangefinder (30m) is suitable for security purpose as a monitor in outdoor environment. Also possible for sticking-out detection.
Description
- Power source: 12VDC±10%
- Detection Range: 0.1 to 30m
- Accuracy: 0.1 to 10m ± 30mm, 10 to 30m ±50mm
- Angular Resolution: 0.25°(360°/1,440 steps)
- Possible for outdoor Applications
- Reflective type with easy wiring
- The LN is an obstacle detection scanner that offers a single output when an object comes into the scanning zone.
Features
- Long distance (30m) and wide angle (270º)
- Reflective type with easy wiring
- This accuracy could be less reliable if the sensor receives strong light such as sun light directly in the outdoor environment
Specifications
- Power source: 12VDC±10% (Current consumptlon: Max:1A, Normal:0.7A)
- Light source: Semiconductor laser diode(?=905nm), Laser safety Class 1(FDA)
- Detection Range: 0.1 to 30m (White Square Kent Sheet 500mm or more), Max.60m 270º
- Accuracy: 0.1 to 10m:±30mm, 10 to 30m:±50mm*1
- Angular Resolution: 0.25º(360º/1,440 steps)
- Scan Time: 25msec/scan
- Sound level: Less than 25dB
- Interface: USB2.0(Full Speed) for field setting by PC
- Output: Output 1:NPN open collector 50mA or less, power less than 30V
- Connection: Power and output: 2m flying lead wire, USB: 2m cable with type-A connector
- Amblent (Temperature/Humidity): -10 to +50 degrees C, less than 85%RH(without dew and frost)
- Vibration Resistance: Double amplitude 1.5mm to 55Hz, 2 hours each in X, Y and Z direction
- Impact Resistance: 196m/s2, 10 times in X, Y and Z direction
- Weight: Approx. 370g(with cable attachment)
