Help CenterHOKUYO DC-JB/JC Electronic Counter With DIN Size
Related Products
-
CSK4-NKW 4 Digit With Zero Clearing Electromagnetic CounterUS$ 3 - 10MOQ: 50 Pieces -
LY-05A 5 Digit Electronic Counter Punching Machine Elactrical CounterUS$ 3 - 10MOQ: 50 Pieces
-
Z94-F Meter Counter Mechanical Rotation CounterUS$ 3 - 10MOQ: 50 Pieces
-
LFC-6S 6 Digit Digital Counter Meter With Zero Clear Electromagnetic CounterUS$ 3 - 10MOQ: 50 Pieces
-
Z96-F Meter Counter Mechanical Rotation CounterUS$ 3 - 10MOQ: 50 Pieces
Specifications
Feature
- Excellent visibility by white LCD
- It can be changed to easy mode or multi mode. It can show the setting condition.
- 12 digits total counter is built-in.(It can show producing numbers per day, month or year)
- Corresponding to each output mode(Self-holding, One-shot, Agree, Comparing)
- Pre-scale function provides.(0.001 to 9.999) Decimal point can be changed.
- Corresponding to each input mode(increment/decrement independence, Phase-difference, Increment, Decrement, Increment/decrement command
- CE Marking, IP66 protection(only front panel with rubber packing), Protecting structure with terminal cover, Key-protection for prevention mishandling provides
-
Specifications Type 1-preset counter 2-preset counter Model No. DC-JB6 DC-JB6 DC-JB6 DC-JB6 DC-JC6 DC-JC6 DC-JC6 DC-JC6 -AW -AY -DW -DY -AW -AY -DW -DY Power source 100 to 240VAC(50/60Hz) 24VDC(ripple 20% or less) 100 to 240VAC(50/60Hz) 24VDC(ripple 20% or less) Fluctuation range ±10% when 24VDC, 85 to 250VAC Power consumption 4VA*1(240VAC) 1W(24VDC) 5VA*1(240VAC) 1W(24VDC) Number of digit 6 digits, -99999 to 999999(Total counter : 12 digits) Memory function EEP-ROM(Re-writing 0.1 million times or more) Counting speed Changeover for 30Hz/5kHz Reset External reset, manual reset, automatic reset Pre-scale 0.001 to 9.999 Decimal point position Lower 4 digits Single-shot time 0.005 to 9.999s Display 7-segment LCD(LED back-light) Input mode Changeover for Increment/decrement independence, Phase-difference, Increment, Decrement, Increment/decrement command Output mode Changeover for One-shot return, Self-holding free, One-shot free, Agree free, Comparing free Output function Changeover for standard or digit-up Standard/Batch/Prediction Input signal Contact or open-collector, Impedance when ON(short-circuit) : 1k ohm or more, Impedance when OFF(short-circuit) : 100k ohm or more, Flowing current when short-circuit : approx. 4mA Control output Transistor output(NPN open-collector) : 100mA or less, 40V or less Contact output(1c,1a*2) : 250VAC/30VDC 3A Resistance load(cosφ=1) Power for sensor 12VDC, 50mA 12VDC, 50mA HOKUYO DC-JB/JC Electronic counter with DIN size HOKUYO DC-JB/JC Electronic counter with DIN size HOKUYO DC-JB/JC Electronic counter with DIN size HOKUYO DC-JB/JC Electronic counter with DIN size HOKUYO DC-JB/JC Electronic counter with DIN size HOKUYO DC-JB/JC Electronic counter with DIN size
Important Information about COUNTER Conditions
1. All of the COUNTER are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The COUNTER guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
