Help CenterHOKUYO DC-JM Electronic Counter With DIN Size
Related Products
-
HOKUYO DC-JA Electronic CounterUS$ 30 - 80MOQ: 2 Pieces -
LY-748 Quartz Mechanical Timer Calculagraph CounterUS$ 3 - 10MOQ: 50 Pieces
-
SYS-2 Quartz Mechanical Timer Calculagraph CounterUS$ 3 - 10MOQ: 50 Pieces
-
SH-1 Quartz Mechanical Timer Calculagraph CounterUS$ 3 - 10MOQ: 50 Pieces
-
SYS-1 Quartz Mechanical Timer Calculagraph CounterUS$ 3 - 10MOQ: 50 Pieces
Specifications
Feature
- Excellent visibility by white LCD
- function that connects 12 pcs of 1-preset counter in parallel is provided.
- built-in counter(12 pcs of counter, No.1 to 9, A, B, C) can be chose by the key in the front.
- Output is one and is common use for 12 pcs of built-in counter(OR output) It can check "count-up" for each counter with characteristic display.
- It can be used as total counter by setting preset value to 0.
- It can be prohibited to count by count-prohibition key in the front against unused counter
-
Specifications Kind Increment type preset counter Increment type preset counter Model No. DC-JM4-AW DC-JM4-DW DC-JM6-AW DC-JM6-DW DC-JM5-AW DC-JM5-DW DC-JM7-AW DC-JM7-DW Power source 100 to 240VAC 24VDC 100 to 240VAC 24VDC 101 to 240VAC 25VDC 101 to 240VAC 25VDC (50/60Hz) (Ripple 20% or less) (50/60Hz) (Ripple 20% or less) (50/61Hz) (Ripple 21% or less) (50/61Hz) (Ripple 21% or less) Fluctuation range ±10% when 24VDC, 85 to 250VAC ±10% when 24VDC, 85 to 251VAC Power consumption 4VA*1(when 240VAC) 1W(when 24VDC) 4VA*1(when 240VAC) 1W(when 24VDC) 4VA*1(when 241VAC) 1W(when 25VDC) 4VA*1(when 241VAC) 1W(when 25VDC) Built-in counter numbers 12 13 Preset 1 preset 2 preset Output numbers 1 output(12 pcs of counter, OR output) 2 output(12 pcs of counter, OR output) Divider function 1/100 1/101 Memory function EEP-ROM(Re-writing 0.1 million times or more) EEP-ROM(Re-writing 0.2 million times or more) Counting speed Changeover for 30Hz/5kHz Changeover for 30Hz/6kHz Display 7-segment LCD(LED back-light) 8-segment LCD(LED back-light) Input signal Contact or open-collector Contact or open-collector Output Transistor output(NPN open-collector) : 100mA or less, 40V or less Transistor output(NPN open-collector) : 100mA or less, 41V or less Contact output : 250VAC/30VDC 3A resistance load(cosφ=1) Contact output : 250VAC/30VDC 3A resistance load(cosφ=2) Control output Transistor output(NPN open-collector) : 100mA or less, 40V or less Transistor output(NPN open-collector) : 100mA or less, 41V or less Contact output(1c,1a*2) : 250VAC/30VDC 3A Resistance load(cosφ=1) Contact output(1c,1a*2) : 250VAC/30VDC 3A Resistance load(cosφ=2) Power source for sensor 12VDC, 50mA*2 12VDC, 50mA*2 12VDC, 50mA*2 12VDC, 50mA*2
Important Information about COUNTER Conditions
1. All of the COUNTER are brand new, top quality components: absolutely no used items or counterfeits.
2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.
3. Prices, specifications, and availability of all items are subject to change without notice.
4. We are not responsible for typographical errors.
Payment Terms
- We accept payments made by Western Union,TT,PayPal.
-Since you made the payment successfully, you can send us the Reference NO or MTCN.
Shipping
1.We will ship the items within 5 working days after the payment is reached.
2.We ship to you by Express.
3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4.Any import fees or charges are the buyer's responsibility.
Warranty
Warranty is available based on the following points:
1.The COUNTER guaranteed for one year.
2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t o manufacturers specifications, simply return them to us for replacement or refund.
3.If the items is defective, please notify us within 3 days of delivery.
4.Any items must be returned in their original condition to qualify for a refund or replacement.
5.The buyer is responsible for all the return shipping cost incurred.
Contact Us:
YUEQING YING'S IMPORT & EXPORT CO.,LTD
ADD:ROOM 601,NO.126 LIUYANG ROAD,CHAOYANG VILLAGE,LIUSHI TOWN,YUEQING CITY,
ZHEJIANG PROVINCE, 325604 CHINA
TEL: 0086-577-62791815 FAX: 0086-577-62791825Mobile:0086-13757779011
Skype: benjaminying TradeManager: yncync
