Home > Electrical & Electronics > Electric Motor > AC Motor > IE2 Standard Synchronous Speed High Efficiency Cast Iron Three Phase Electric Motor
IE2 Standard Synchronous Speed High Efficiency Cast Iron Three Phase Electric Motor
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
HALOTOP Motor
Model Number:
6 Pole T2C Motor
Type:
Asynchronous Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
China Sea Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
IE2 Standard Single-Phase Capacitor Start Asynchronous Motors Aluminum Housing MC801 2NegotiableMOQ: 1 Set -
IE1 Standard Three Phase Asynchronius Motors Aluminum Housing MS561 2NegotiableMOQ: 1 Set
-
IE2 UL Approved Synchronous 30KW 90KW Cast Iron Three Phase Electric MotorNegotiableMOQ: 1 Set
-
IE2 Standard Three Phase Asynchronous Motors Aluminum Housing At 400V 50HZ MS2 100L 6NegotiableMOQ: 1 Set
-
IE Standard Three Single Phase Aluminum Housing Saw Motors MSC74A2NegotiableMOQ: 1 Set
Brand Name
HALOTOP Motor
Model Number
6 Pole T2C Motor
Type
Asynchronous Motor
Frequency
50HZ Motor
Output Power
5.5-22KW Motor
Protect Feature
Totally Enclosed
Phase
Three-phase
Certification
CE, UL
AC Voltage
Other, 400V
Place of Origin
Shanghai, China
Efficiency
IE 2
Specifications
1. IE2 Standard Three Phase Electric Motor2.UL CE Certified Motor
3.6 Pole Motor
4.Cast Iron Motor
IE2 Standard Synchronous Speed High Efficiency Cast Iron Three Phase Electric Motor
| Features |
| 1.Energy saving, high efficiency |
| 2.High starting torqaue,lower starting current |
| 3.Versatile design(easy to modify for varieties of application |
| 4.Option of integrated or removable foot |
| 5.Option of aluminum housing up to frame size 200 |
| 6.Option of terminal box location(top, left or right) |
| Applications |
| 1.Pumps |
| 2.Waste water treatment plant |
| 3.Air compressors, fans |
| 4.Gear reducers and power transmission |
| 5.Pulp and paper mill |
| 6.Steel mill |
| 7.Conveyors, elevators |
| 8.Should be "Material handling equipments" |
| 9.Agricultural applications |
| 10.Mining equipment |
| 11.Hydraulic equipments |
| 6 Pole-1000 rpm Synchronous Speed 50Hz | |||||||||||
| Model | Power (KW) |
Full Load Speed (r/min) |
Inl400V (A) |
Ifl400V (A) |
Ist/In (Times) |
Eff. 100%FL (%) |
Power Factor (Cosφ) |
Full Load Torque (N.M) |
Tst/Tn (Times) |
Tmin/Tn (Times) |
Tmax/Tn (Times) |
| 132M2-6 | 5.5 | 945 | 4.97 | 11.26 | 6.8 | 86 | 0.82 | 55.58 | 2.3 | 1.9 | 2.8 |
| 160M-6 | 7.5 | 955 | 6.16 | 14.78 | 7 | 87.2 | 0.84 | 74.99 | 2.4 | 1.9 | 2.7 |
| 160L-6 | 11 | 960 | 8.5 | 21.06 | 7.3 | 88.7 | 0.85 | 109.42 | 2.5 | 2 | 2.8 |
| 180L-6 | 15 | 960 | 12.48 | 29.08 | 7.8 | 89.7 | 0.83 | 149.21 | 2.3 | 2.1 | 2.9 |
| 200L1-6 | 18.5 | 965 | 14.03 | 34.75 | 7.8 | 90.4 | 0.85 | 183.07 | 2.4 | 2.1 | 3.2 |
| 200L2-6 | 22 | 965 | 15.86 | 40.62 | 7.9 | 90.9 | 0.86 | 217.7 | 2.3 | 1.9 | 3.1 |
