70KW FIRE FIGHTING DIESEL ENGINE WITH FOUR CYLINDERS

Name: 70KW FIRE FIGHTING DIESEL ENGINE WITH FOUR CYLINDERS
Brand: HALOTOP
SKU: 141199196
Availability: InStock

US$ 1,000 - 5,000 MOQ: 10 Units

Key Specifications

Brand Name:

HALOTOP

Model Number:

HT4105

Shanghai Halotop Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Brand Name HALOTOP

Model Number HT4105

Product Description

FORM A:

Specification of Diesel Engines
MODEL	HT380	HT480	HT485	HT490	HT4100	HT4102	HT4105	HT4108
TYPE	VERTICAL,WATER-COOLED,FOUR-STROKR,DIRECTION-INJECTOR
NUMBER OF CYLINDERS	3	4	4	4	4	4	4	4
BORE*STROKE(MM)	80*90	80*90	85*95	90*100	100*105	102*118	105*118	108*118
RATE POWER(KW)	20	27.8	34	42	58	63.8	70	80
RATE POWER(HP)	27	37	46	58	78	87	95	110
RATE SPEED(R/MIN)	2900	2900	2900	2900	2900	2900	2900	2900
TOTAL DISPLACEMENT(L)	1.357	1.809	2.156	2.54	3.298	3.857	4.087	4.324
MAX.TORQUE(N.M)	72.6	99.8	118.2	149.7	193.1	231.8	260	280
MIN.SPECIFIC FUEL CONSUMPTION AT FULL LOAD	247	247	262	247	238	238	238	238
DIRECTION OF CRANKSHAFT ROTATION(FACING TO FLYWHEEL)	COUNTER-CLOCKWISE
LUBRICATING METHOD	PRESSURRE AND SPLASH LUBRICATING
STARTING METHOD	ELECTRIC STARTING
NET MASS(KG)	230	250	260	300	350	360	380	400

FORM B:

Specification of Diesel Engine
MODEL	HT6102BQ	HT6102BZQ	HT6102BZS	HT6112T	HT6120T	HT6120Ti	HT6126Ti-1	HT6126Ti-2
TYPE	VERTICAL,WATER-COOLED,FOUR-STROKR,DIRECTION-INJECTOR
NUMBER OF CYLINDERS	6	6	6	6	6	6	6	6
BORE*STROKE(MM)	102*118	102*118	102*118	112*135	120*130	126*130	126*130	126*130
RATE POWER(KW)	95	110	125	150	165	200	245	275
RATE POWER(HP)	130	150	170	204	225	272	334	374
RATE SPEED(R/MIN)	2900	2900	2900	2900	2900	2900	2900	2900
TOTAL DISPLACEMENT(L)	5.785	5.785	5.785	7.98	8.82	8.82	9.73	9.73
MAX.TORQUE(N.M)	372	420	470	760	1250	1250	1640	1640
MIN.SPECIFIC FUEL CONSUMPTION AT FULLLOAD	205	205	205	201	201	201	203	203
DIRECTION OF CRANKSHAFT ROTATION(FACING TO FLYWHEEL)	COUNTER-CLOCKWISE
LUBRICATING METHOD	PRESSURRE AND SPLASH LUBRICATING
STARTING METHOD	ELECTRIC STARTING
NET MASS(KG)	580	580	580	1200	1300	1300	1400	140
