Home > Industrial Equipment & Components > Engine & Part > Engine > Single Cylinder Air Cooled Diesel Engine 186FA(E)
Single Cylinder Air Cooled Diesel Engine 186FA(E)
Negotiable
MOQ: 10 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, Pump
Fuel:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
IN-LINE PUMP ENGINE FOR GENERATING SET 1006C P6TAG4 GENSET ENGINENegotiableMOQ: 1 Piece -
ROTARY PUMP DIESEL GENSET ENGINE 1006TAGNegotiableMOQ: 1 Piece
-
ROTARY PUMP GENSETS ENGINES 1006TG2ANegotiableMOQ: 1 Piece
-
IN-LINE PUMP GENSETS DIESEL ENGINES 1003G-26KWNegotiableMOQ: 1 Piece
-
IN-LINE PUMP ENGINE FOR GENERATING SET-1004TG 84.3KWNegotiableMOQ: 1 Piece
Condition
New
Usage
Other, Pump
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Single Cylinder
Cold Style
Other, Air-cooled
Start
Electric Start
Place of Origin
Jiangsu, China
Brand Name
HALOTOP
Model Number
186F(E)
Dimension(L*W*H)
420*440*495mm
Weight
48kg
Certification
ISO9001&CE
Specifications
1. Air cooled diesel engine2. Single cylinder
3. Output: 10HP
4. ISO9001 & CE certificate
Product Description
single cylinder air cooled diesel engine 186FA(E)
diesel engine / air cooled diesel engine / single cylinder diesel engine
| Diesel Engine | ||
| Model | SD186FA(E) | |
| Engine Type | Single cylinder,vertical,4 stroke,air cooled,diesel engine,direct injection | |
| Bore*Stroke(mm) | 88*72 | |
| Displacement(L) | 418 | |
| Combustion Ration | 19:01 | |
| Rated power(kw/rpm) | 5.7 | 6.3 |
| Rated Speed(rmp) | 3000 | 3600 |
| The lowest speed at zero load(rpm) | ≤1300 | |
| Rotation direction(view from the flywheel) | Anticlockwise | |
| Starting System | Recoil or Electric starter | |
| Lube oil type | SAE10W-30,SAE20W-40 or L-ECD grade(above) | |
| Fuel type | Diesel | |
| Fuel consumption(g/kwh) | 275 | |
| Fuel tank capacity(L) | 5.5 | |
| Lube Oil Capacity(L) | 1.65 | |
| DIM LXWXH(mm) | 420*440*495 | |
| N.W.(kg) | 48 | |
