Raised Access Floor System

Raised access floor System

 Concentrated load is 4500N

Uniform load is 12000N/M²

PVC laminated

Panel thickness is 45MM

Color and Patern of PVC is optional

Electrical resistance   2.5x 10⁴ to 10^{6 ohm}

Static Generation AATCC-134 less than 100volts with conductive footwear per AATCC-134 at 20% relative humidity

Abrasiona resistance ASTM D-1044 CS-10-F wheel, 500Gm Weight

Cycles   %Gauge Loss

2500       0.40

5000       0.80

7500       1.20

10000     1.60

Resistance to wear EN660-1/DIN 51955    M

Scope of application:
Anti-static floor applies to activities controlled room, computer rooms and other electronic equipment for the microelectronics control room, clean room to prevent electrostatic hazard sites; It is not only laying the ground-room electrostatic equipment, but also as a place of light equipment, the floor under the cable alignment, such as the laying of pipelines and other ground facilities.
