Cast Iron Gate Valve

cast iron gate valve

Specifications

Cast iron gate valve
Size: 2"~48"
Connection: RF/RTJ Flange, Butt Welded
Pressure Rating: Class 150Lb~ Class 2500Lb

Cast Iron Gate Valve

• Size: 2"~48"
• Connection: RF/RTJ Flange, Butt Welded
• Pressure Rating: Class 150Lb~ Class 2500Lb
• Material: Cast Steel, A216 Gr. WCB, , A351 CF8, A351 CF8M

Design Standard:

• Manufacture in accordance with API 6D or API 600
• Face to face/End to End Dimensions to ANSI B 16.10
• Flange Dimensions to ANSI B 16.5
• Butt-welding End Dimensions to ANSI B 16.25
• Valve Tested to API 6D or API 598

Structural Features

• Full port design
• OS&Y, Outside screw and yoke
• BB. Bolted bonnet
• Flexible wedge , fully guided
• resilient seated
• choice solid or split wedge
• renewable seat rings.
• rising stem or non -rising
• handwheel operated
• flanged or buttwelding ends.

Quotation Reminder

To make a suit solution for the project , we need follow information.

• Design standard.
• Connection standard .
• Size.
• Body material .
• Trim (Material for inside parts).
• Connection type.
• Operation type.
• Medium.
• Temperature.
• Ambient temperature range . Corrosion considerations.
• Application Descripetion.
• Painting color.
• Label content.
