Specifications
1. pe material as raw material2. good output
3. high efficiency
Structural characteristics:
1. LD (L) series agricultural film blowing machine is applicable for producing agricultural film (0.003mm-0.009mm .04-0.08mm) of LDPE, LLDPE, and LLDPE/LDPE blend.
2. The die adopts advanced central head feeding spiral runner molding technology.
3. Molding and cooling of the film adopts air blower and air ring with high-property, low air pressure, and large air volume.
4. The extruder adopts corrugated screw with oblique barrier and mixing head, which assures stable and reliable performance, high output and low energy consumption.
5. It adopts friction type double surface wind-up, which has improved the flatness of the film, and made the coiling structure tight. It is easier to operate. A length metering device is installed, which makes the length of the film accuracy.
6. The electrical components are domestic famous brand.
Main technical parameters:
Model | LD1100 | LD1300 | LD1600 | LD2200 | LD2500 | LD2650 | LD2800 |
Max. folding width of ground film | 1,000 | 1,200 | 1,500 | 2,000 | 2,300 | 2,500 | 2,600 |
Max. folding width of farm film | 800 | 1,000 | 1,300 | 1,800 | 2,100 | 2,300 | 2,400 |
Ground film thickness | 0.003-0.009 | ||||||
Farm film thickness | 0.04-0.08 | ||||||
Outputs kg/h | 50 | 52 | 110 | 130 | 180 | 220 | 240 |
Applicable material | LDPE, LLDPE, LDPE/LLDPE LDPE, LLDPE, LDPE/LLDPE Blend | ||||||
Screw diameter | 45 | 50 | 65 | 75 | 75 | 90 | 90 |
L/D of screw | 30 | 28 | 28 | 28 | 30 | 30 | 30 |
Max. rotating speed of screw | 130 | 130 | 140 | 105 | 110 | 120 | 120 |
Type of the main motor |
Can be matched by the requirements of the customer | ||||||
Power of main motor | 15 | 18.5 | 37 | 45 | 55 | 75 | 90 |
Die head type | Spiral die head | ||||||
Highest speed for ground film coiling | 120 | 120 | 120 | 120 | 100 | 80 | 80 |
Highest speed for farm film coiling | 30 | ||||||
Total power | 28 | 32.5 | 72 | 80 | 88 | 105 | 180 |
Overall dimensions | 6.2×2.3×5 | 6.4×2.5×5 | 6.6×3×6.8 | 7.5×2.5×7.7 | 7.8×3.2×10.5 | 8×3.5×10.5 | 13×4×9 |
Weight | 5.2 | 5.5 | 6.5 | 8.5 | 16 | 19.5 | 21 |
