Drip Irrigation Tape Production Line Labyrinth Type Drip Irrigation Belt Machine
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Water-saving Device Singe-blade Labyrinth Type Drip Irrigation Machine
-
SJ-DG-60 Labyrinth Type Drip Irrigation Tape Extrusion Machine
-
SJ Series Inline Cylindrical Agricultural Irrigation Pipe Machine Price
-
Plastic Machinery: Multi-layer Co-extruding Plastic Greenhouse Film Plant
-
Multi-layer Co-extruding Plastic Greenhouse Film Equipment
-
Plastic Machine: Multi-layer Co-extruding Plastic Shed Film Plant
Product Details
| Place of Origin | Shandong, China | Brand Name | Hengxiang | |
| Model Number | SJ-65/30 | Material | PE | |
| Specification | 1.8L/H-3.2L/H | Length | 400m/roll | |
| Thickness | 0.01-0.2mm |
Product Description
Specifications
china manufacturer Labyrinth type drip irrigation belt is wide used for the irrigation of farmland and greenhouse plantiConfigurations and Quotation
Equipment Title | Single-Wing Labyrinth Drip Irrigation Tape Machine | ||||||
Models | MDGD-60 | MDGD-65 | SM DGD 50/50 | SM DGD 55/55 | |||
Extruders | Models | SJ-60/30 | SJ-65/30 | SJ-50/30×2 | SJ-55/30×2 | ||
Screw diameter | Φ60 | Φ65 | Φ50 | Φ55 | |||
L/D | 30 | 30 | 30 | 30 | |||
Rotating speed | 90R/Min | 100R/Min | 90R/Min | 100R/Min | |||
Total heating power | About 13 kw | About 15kw | About 18kw | About 19.5kw | |||
Central height | 810mm | 400mm | 810mm | 400mm | |||
Main motor | 18.5kw (4 grade) three phase asynchronous motor + frequency control | 22kw (6 grade) three phase asynchronous motor + frequency control | 15kw (4 grade)×2 three phase asynchronous motor + frequency control | 15kw (6 grade)×2 three phase asynchronous motor + frequency control | |||
Gear box | GB-173 | GB-200 | GB-146×2 | GB-173×2 | |||
Die head | Φ55 | Φ55 | Φ55 double-layer | Φ55 double-layer | |||
Traction device | Traction mode | Four-roller type | |||||
Traction motor | three phase asynchronous motor | ||||||
Speed control mode | Frequency control | ||||||
Motor power | 0.75kw | 1.1kw | 0.75kw | 1.1kw | |||
Reducer model | WPA60 | ||||||
Max. traction speed | 40m/min | 55m/min | 40m/min | 55m/min | |||
Mould wheel | Motor | 0.75KW | 1.1KW | 0.75KW | 1.1KW | ||
Motor ratio | 60:1 | 40:1 | 60:1 | 40:1 | |||
Dia. of wheel | Φ477.2 or Φ451 | Φ477.2 | Φ477.2 or Φ451 | Φ477.2 | |||
Emitter space | 150, 200, 250, 300, 400, 500, 600 mm etc (customer selected) | ||||||
Flow rate | 1.2L/H---4.5L /H (customer selected) | ||||||
Coiling device | Coiling mode | Two-position | Three-position | Two-position | Three-position | ||
Motor | Torque motor 6/6N.M | ||||||
Central height | 112mm | ||||||
Electrical cabinet | 5 sections temperature control | 5 sections temperature control | 11 sections temperature control | 11 sections temperature control | |||
Frequency converter | |||||||
Line speed | 30m/min ×2 | 40m/min×2 | 30m/min×2 | 40m/min×2 | |||
Brands | Motor | Siemens | |||||
Temperature controller | Omron | ||||||
Frequency controller | Siemens | ||||||
Low voltage components | Siemens | ||||||
Quotation for each machine | FOB Qingdao USD 39 thousand | FOB Qingdao USD 42 thousand | FOB Qingdao USD 43 thousand | FOB Qingdao USD 45 thousand | |||
