495P K4100P R4105ZP R6105ZP R6105AZLP R6105IZLP Diesel Engine Weifang Weichai
| TECHNICAL DATA | ||
| Diesel engine model | R6105AZLP | |
| Type | water-cooled, inline, 4-storkes, direct injection combusion chamber | |
| Constant Output (kW/kVA) | 132/165 | |
| Speed (r/min) | 2000 | |
| Cylinder No.-Bore*Stroke(mm) | 6-105-130 | |
| Total Displacement of Piston(L) | 6.49 | |
| Pressure Ratio | 17 | |
| Air Intake Type | Turborchanged | |
| Fuel Consumption(g/kw/.h) | 224 | |
| Oil Consumption(g/kw.h) | 1.63 | |
| Exhaust Temperature(°C) | 600 | |
| Crankshaft Ratating | Inverse Hour (Facing the power output end) | |
| Cooling Type | Forced Water Cooling | |
| Lubricating Type | Compound type with pressure and splash | |
| Starting Type | Electric Start | |
1) General Instruction of our diesel engine
a, Assembled with radiator, clutch and belt pulley, start, charging alternator.
b, It can be connected your machine by belt. It can supply and transmission the power to your machine,drive your machine to work.
2) Advantages and main features of our diesel engines
a, Enough storage power, can be on 100%,110% loading in normal and standby urgent condition.
b, Low fuel consumption.
c, Easy start after matched with large power starter and alternator.
d, Strong Power fuel pump, can guarantee whole machine in steady status working condition.
e, Easy to repair, and low cost of maintenance
f, 2 years warranty, technical consultation free of charge life time.
3) why we can supply 2 years warranty period
a, Big power starter, can make the engine start to easy.
b,Strong power fuel pump,supply enough power,
c,Reliable quality cylinder block.
d,Radiator has good radiating and cooling effect, even in 40 centi degree area.
