| TECHNICAL DATAS | |
| Diesel engine model | HTR6105IZLD |
| Type | water-cooled, inline, 4-storkes, swirl combusion chamber |
| Constant Output (kW/kVA) | 132/165 |
| Speed (r/min) | 1800 |
| Cylinder No.-Bore*Stroke(mm) | 6-105×135 |
| Total Displacement of Piston(L) | 6.75 |
| Pressure Ratio | 16:01 |
| Air Intake Type | turbocharger |
| Fuel Consumption(g/kw/.h) | ≤239 |
| Oil Consumption(g/kw.h) | ≤1.63 |
| Exhaust Temperature(°C) | ≤600 |
| Crankshaft Ratating | Inverse Hour (Facing the power output end) |
| Cooling Type | Forced Water Cooling |
| Lubricating Type | Compound type with pressure and splash |
| Starting Type | Electric Start |
| Manufacturer | Weifang Huatian Diesel Engine Manufacture Co., Ltd |
| Brand | HUATIAN |
Features of genset
1. Timely Warranty Service, Warranty: One year or 1000 Working Hours from the shipment date, whichever comes first.
2. Short delivery time.
3. With ISO9001&CE certification
4. Spare parts are easy to get from worldwide market with much cheaper price
5. Coupled with all kinds of brand engine & alternator.
6. Perfect after-service network
7. Both 50Hz and 60Hz
8. Strict test including 50% load,75% load,100% load and 110% load
warehouse
production
Weifang huatian Diesel Engine Co., Ltd, is located in weifang city, of Shandong province.Hundreds of workers , 10 years experience, CE and ISO9001 certificated, less two hour reach Qingdao port. So far ,we already set up more than 20 sole agencies and dealer in the whole world ,such as Australia, Europe, Southeast Asia, East-Asia, Mid-east, America and Africa. Supply the fast and efficient after sales service. that’s how we keep superior quality and global valued customers.
