US$ 750 - 6,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Usage:
Other, Generator
Fuel:
Diesel
Stroke:
4 Stroke
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Usage
Other, Generator
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Multi-cylinder
Cold Style
Other, Water-cooled
Start
Electric Start
Place of Origin
Shandong, China
Brand Name
Steyr
Model Number
6126ZLD
Specifications
1)Generator Engine2)10kw-230kw
3)Water Cooling
4)Lifetime Service
5)2 Years Warranty
1, Generator Engine Specification,
| Diesel Model | R6126ZLD |
| Rated/Prime Power(kw/hp/rpm) | 200/272/1500 |
| 110% Loading Power(kw/hp/rpm) | 220/300/1500 |
| Rated Speed(rpm) | 1500/1800/2000/2200 |
| Type | Water Cooling, Inline, Direct Injection, 4 Strokes |
| Displacement of Piston(L) | 9.7 |
| Cylinder Number | 6 |
| Bore*Strokes(mm) | 126*130 |
| Air Intake Model | Turbocharged and Inter Cooled |
| Fuel Consumption(L/H) | 48 |
| Piston Speed(m/s) | 6.25 |
| Mechanical Governor Rate | ≤5% |
| Electronical Governor Rate | ≤1% |
| Noise Level(dBA) | ≤95 |
| Cooling Model | Forced Water Cooling by Radiator |
| Start Model | Electric by Battery |
| Cransshaft Rotation Direction | Inverse Hour(Facing to the power output end) |
| Application | Generator |
| Packing Dimension(mm) | 1500*850*1700 |
| Gross Weight(kg) | 700 |
2, Optional Configuration
1), Radiator
a, Aluminum or Copper
b,With or Without Protection Cover
 |
3, Electric System
a, Mechanical/Electrical Governor Pump
b,Stop Solid can be optional.
c,Diesel Engine Protection Panel. The panel will be alarm, stop and protect the engine, in urgent working condition. Such as high temperature, low oil pressure, overspeed,etc.
|
4,Flywheel
With or without SAE.
|
4),Packed by Standard Export Seaworthy Wooden cases.
|
5),Any color is optional.
