Home > Chemicals > Rubber & Rubber Products > Rubber Tube, Pipe & Hose > Flexible Soft Hollow Silicone Rubber Tubing, Food Grade, ROHS, Eco-friendly ASR1002
Flexible Soft Hollow Silicone Rubber Tubing, Food Grade, ROHS, Eco-friendly ASR1002
US$ 0.12 - 0.28
MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Xindong
Model Number:
ASR1002
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
White High Temperature Silicone Rubber Tubing, Food Grade, ROHS, Eco-friendly ASR1003US$ 0.12 - 0.28MOQ: 1000 Meters -
Colored Silicone Rubber Tubing, Silicone Tube And Hose ASR1090US$ 0.12 - 0.28MOQ: 1000 Meters
-
Clear Silicone Rubber Tubing, China Silicone Tube and Hose ASR1091US$ 0.12 - 0.28MOQ: 1000 Meters
-
High Pressure Silicone Tubing ASR1092US$ 0.12 - 0.28MOQ: 1000 Meters
-
Conductive Silicone Tubing ASR1093US$ 0.12 - 0.28MOQ: 1000 Meters
Place of Origin
Guangdong, China
Brand Name
Xindong
Model Number
ASR1002
Specifications
Silicone Tubing1.Approval: ROHS
2.Common wall thickness: +/-0.2mm
3.Operating Temperature: -60C~+250C
4.Retard Fire
Silicone Rubber Tube ASR1027
1. Approval: ROHS Black Rubber Foam Insulation Tubes
2. Common wall thickness: +/-0.2mm
3. Operating Temperature: -60C~+250C
|
The Silicone Rubber Tube of heat resistance is also called Flame Retardant Silicon Rubber Hose, which consists of Extrusion Tube and Special-shaped Tube or Strip. The Flame Retardant Silicon Rubber Hose is made by Common Silicone Rubber which refined into double roll mixing machine or closed kneading machine together with flame retardant. As the flame retardant grade, the Flame Retardant Silicon Rubber Hose is divided into UL94HB, UL94V2, UL94V1, UL94V0 and DIN5510. | ||||
| Item | Unit | Test Standard | Targeted Value | |
| Hardness | HA | GB/T 6031-1998 | 50-80 | |
| Appearance | White or grey | |||
| Proportion(25°C) | g/cm3 | GB/T 533-1991 | 1.15-1.26 | |
| tensile strength | MPa | GB/T 528-1998 | 6.5-8.5 | |
| elongation at break | % | GB/T 528-1998 | ≥180 | |
| tensile set | % | GB/T 528-1998 | 6.0-8.0 | |
| tearing strength | kN/m | GB/T 529-1999 | ≥9 | |
| Temperature Renge | °C | -60°C-200°C | ||
Specifications:
| Size | Diameter | Thickness | ||
| I.D. | O.D. | Standard | Minimum | |
| 0.8*1.8 | 0.8±0.1 | 1.8±0.1 | 0.5 | 0.38 |
| 1.0*2.0 | 1.0±0.2 | 2.0±0.2 | 0.5 | 0.38 |
| 1.2*2.2 | 1.2±0.2 | 2.2±0.2 | 0.5 | 0.38 |
| 1.5*2.5 | 1.5+0.4/-0.2 | 2.5+0.4/-0.2 | 0.5 | 0.38 |
| 2.0*3.0 | 2.0+0.4/-0.2 | 3.0+0.4/-0.2 | 0.5 | 0.38 |
| 2.5*3.5 | 2.5+0.4/-0.2 | 3.5+0.4/-0.2 | 0.5 | 0.38 |
| 3.0*4.0 | 3.0+0.4/-0.3 | 4.0+0.4/-0.3 | 0.5 | 0.38 |
| 3.5*4.5 | 3.5+0.4/-0.3 | 4.5+0.4/-0.3 | 0.5 | 0.38 |
| 4.0*5.0 | 4.0+0.5/-0.4 | 5.0+0.5/-0.4 | 0.5 | 0.38 |
| 4.5*5.5 | 4.5+0.5/-0.4 | 5.5+0.5/-0.4 | 0.5 | 0.38 |
| 5.0*6.0 | 5.0+0.5/-0.4 | 6.0+0.5/-0.4 | 0.5 | 0.38 |
| 6.0*7.0 | 6.0+1.0/-0.5 | 7.0+1.0/-0.5 | 0.5 | 0.38 |
| 7.0*8.4 | 7.0+1.0/-0.5 | 8.4+1.0/-0.5 | 0.7 | 0.56 |
| 8.0*9.4 | 8.0+1.0/-0.5 | 9.4+1.0/-0.5 | 0.8 | 0.56 |
| 9.0*10.6 | 9.0+1.0/-0.5 | 10.6+1.0/-0.5 | 0.8 | 0.68 |
| 10*11.6 | 10.0+1.0/-0.5 | 11.6+1.0/-0.5 | 0.8 | 0.68 |
| 11.0*13.0 | 11.0+1.0/-0.5 | 13.0+1.0/-0.5 | 1 | 0.89 |
| 12.0*14.0 | 12.0+1.0/-0.5 | 14.0+1.0/-0.5 | 1 | 0.89 |
| 13.0*15.0 | 13.0+1.0/-0.5 | 15.0+1.0/-0.5 | 1 | 0.89 |
| 14.0*16.0 | 14.0+1.0/-0.5 | 16.0+1.0/-0.5 | 1 | 0.89 |
| 15.0*17.0 | 15.0+1.0/-0.5 | 17.0+1.0/-0.5 | 1 | 0.89 |
| 16.0*18.0 | 16.0+1.0/-0.5 | 18.0+1.0/-0.5 | 1 | 0.89 |
| 17.0*19.0 | 17.0+1.0/-0.6 | 19.0+1.0/-0.6 | 1 | 0.89 |
| 18.0*20.0 | 18.0+1.0/-0.6 | 20.0+1.0/-0.6 | 1 | 0.89 |
| 19.0*22.0 | 19.0+1.0/-0.6 | 22.0+1.0/-0.6 | 1.5 | 1.35 |
| 20.0*23.0 | 20.0+1.0/-0.6 | 23.0+1.0/-0.6 | 1.5 | 1.35 |
| OEM is accepted, the size and color could as customer's request. | ||||
