High Quality Ice Hockey Equipment,EPDM Ice Mat,UV, Aging Resistance

Specifications

  ice hockey equipment for ice rink

1.EPDM cooling mats system is based on a simple principle that involves our EPDM mats being rolled out onto a previously laid out insulating layer.

2.The distribution pipes are connected simply using quick couplings. Ice skating rinks can thus be assembled within 2 - 4 hours with great flexibility in terms of size and shape.

3. Our edging is joined together and frozen into the ice for better stability.

4. The distribution pipes are equipped with an accessible, vandal-proof cover as standard.

Extremely low energy consumption

Our technology enables optimal results through the use of the latest generation of computer-controlled cooling machines with low energy consumption and thus low energy costs. For instance, even in the warmest winter months for an ice rink measuring 600 m², power costs remain below 2.600,00 €/month (for comparison purposes: systems are often said to be energy-saving, even though they use three times as much energy as our systems).

Item: ice rink mat

Material: EPDM

Ice rink mat width: 117mm; There are 8 hosepipes in one ice mat. (each hosepipes outside diameter: about 10mm, inner diameter: about 7mm.)

Ice rink mat Length: Customized

Ice rink mat weight: Empty: 5,5 kg/m2

                Full: 8,5 kg/m2 - contents 3,0 l/m2

Flow Rate per m2: 50 to 100 l/h

operational Pressure: 0,5 to 2,5 bar

Temperature Range: -40°C to + 120°C
