Specifications
Y Series Three Phase Electric Motor1) 0.75-315kW; 1-430HP
2) 80-355MM; 50/60Hz; 100-800V
3) IM B14/B3/B34/B35/B5
Products Induction
Y series three phase asynchronous electric motor is a kind of low-voltage squirrel cage 3-phase induction motor. They are totally enclosed, fan-cooling newly designed and to be in conformity with the relevant requirements & rules of JB/T10391-2002 & IEC standards.
Y motor have the advantage of high efficiency, long working life, energy saving, high starting torque, low noise, small vibration, big breakaway torque, reliable operation performance, easy & convenient maintenance.
Y motor are widely used in many fields, such as machine tools, pumps, fans, transport machinery, mixer, agriculture machinery, food machines, agitator, air compressor etc. However, Y series three phase asynchronous electric motors are unsuited to be used in that place where combustible, explosive or corrosive gas exist and other special requirements forbidden.
For the Connection Model of Y motor, please refer to the Nameplate on the motor. (The Y Connection is adopted by motors' Output equal or below 3 KW; The Delta-Connection is adopted by motors' Output above 4 KW).
Y Motor can be equipped with PTC.
For motor of frame size 160MM and above can be equipped with re-greasing system.
Service Conditions
--Ambient Temperature: -15°C~40°C
--Altitude: not exceed 1000 Meter
--Rated Voltage: 380V or any voltage between 220-760V
--Rated Frequency: 50Hz/60Hz
--Protection Class: IP44, IP54, IP55
--Insulation Class: B/F
--Cooling Method: IC0141
--Working Duty: S1(Continuous)
-- Humidity: Lower than 90%
--Connection: Star-connection for up to 3Kw; Delta-connection for 4Kw and above
Any inquiry on electric motor,water pumps, sand pumps, please contact me.
