Help CenterHigh Accuracy AC Voltage Stabilizer(AVR) SVC-1500VA
Related Products
-
High Accuracy Full Automatic Voltage Stabilizer SVC-500VAUS$ 13 - 14MOQ: 1 Piece -
Single Phase High Accuracy Full Automatic Stabilizer(AVR) SVC-1000VA/1kvaUS$ 17 - 18MOQ: 1 Piece
-
Push Utton Switch JHB2-B SeriesUS$ 1 - 2MOQ: 50 Pieces
-
Push Button Switch,take the Spring Coil Button Function Sign,button StopUS$ 1 - 2MOQ: 50 Pieces
-
Mushroom Head Push Button Switch JHB2-B SeriesUS$ 0.5 - 1MOQ: 50 Pieces
SVC type AC Automatic Voltage Regulator(stabilizer)
1.Model No.
SVC500VA, 1000VA, 1500VA, 2000VA, 3000VA, 5000VA, 10KVA
2.General:
When the voltage fluctuates or the load varies, automatic sampling control circuit
will send a signal to drive the servo motor which can adjust the position of carbon
brush, then the output voltage will be adjusted to rated value and get a steadystate.
3.Parameters:
Input voltage: 150-250V (1P)
Output voltage: 220V and 110V
Stabilization accuracy: 220V±3% and 110V±6%
Frequency: 50Hz/60Hz
Debug time: ≤1s (with the input voltage variation of 10%)
Overload power factor: 0.8
Efficiency: ≥90%
Dielectric strength: 1,500V/min
over voltage: 246±4VAmbient t
emperature: -10±40°CRelative
humidity: ≤95%
Temperature rise: lower than 60°
CWave form distortion: no additional wave form distortionInsulation
resistance: ≥2MΩ
