RECYCLED POLYESTER STAPLE FIBER MAKING MACHINE,
POLYESTER STAPLE FIBER MAKING MACHINE
PSF MACHINE
Specifications
PSF PRODUCTION LINE, POLYESTER FIBER PRODUCTION LINE
1.Capacity: 5 - 100 TONS/DAY
2.Raw material : PET flakes
1. Company and product details
1.1 Company Profile
At Cissco, we design, engineer and manufacture customized plastic extrusion lines. There is a proven Cissco technology for virtually every extrusion line application. Our extensive knowledge of the industry - its raw materials, processes and finished products - provides reliability, cost optimization and on-time delivery, the same benefits that you would expect from proven pre-engineered components, all in a system designed and tailored to your unique requirements.
To ensure the efficiency, productivity and safety of our systems, we offer extensive start-up assistance, comprehensive training and operator manuals. When you have service needs, you can count on an immediate response from your nearest Cissco facility, one of many we have located strategically throughout the world.
For the best investment decision or further details please do not hesitate to contact to us at your earliest convenience. You can also refer to our website to browse other product categories.
1.2 Product details
The PSF production line can be used to produce polyester, polypropylene, polyamide and other staple fiber. PET stable fibers have a variety of different uses: in the cotton spinning industry such as, singly spinning or spinning together with cotton along with, viscose, fiber, fur and vinyl. For instance, the clothing material for pillows. Also, they are widely used as shell fabric, packing cotton, filling material, thermal insulation materials and waterproof cotton.
Corresponding to technical equipment adjustment, it will be used to produce three-dimensional hollow fiber and other special chemical fiber. The mainframe is diveded into two main parts, the prevenient filature and post filature.
2. Components and Processes of the PSF production line
2.1 Fore spinning Line:
Vacuum Dryer -> Hopper -> Screw Extruder -> Filter -> Spin Beam (Meter Pump System, Spin Pack, Spinneret) -> Quenching Unit -> Interfloor Duct -> Draw-off Wall -> Capstan Roller -> Sunflower Gearing unit -> fiber can traverse system.
2.2 After spinning Line:
- if 2-Dimensional Hollow Fiber:
Can Creel -> Inlet Thread Guide -> Tow Guide Stand -> Dipping Bath -> 1st Draw Stand -> Draw Bath -> 2nd Draw Stand -> Draw Steam Chest -> 3rd Draw Stand -> Tow Stacker -> Crimper Steam Box -> Crimper -> Tow Conveyer -> Relaxer -> Tow Tension Stand -> Cutter -> Chain Plate Conveyor -> Baling Press
- if 3-Dimensional Hollow Fiber:
Can Creel -> Inlet Thread Guide -> Tow Guide Stand -> Dipping Bath -> 1st Draw Stand -> Draw Bath -> 2nd Draw Stand -> Draw Steam Chest -> 3rd Draw Stand -> Tension Control Device -> Tow Stacker -> Crimper Steam Box -> Crimper -> Silicon Oil Sprayer -> Tow Tension Stand -> Cutter -> Fiber Spreader -> Fiber Leveler -> Relaxer -> Chain Plate Conveying system -> Baling Pressrecycled psf production line
2.3 Parameters comparison:
3. Picture of the different components and processes of the PSF production line
5. Contact details
Tareq Muwanes
CissCo Machinery Co., Ltd.
Mob.: +86 13701714184 I Office: +86 2138726398/99
Email: arab@ I Skype: almqes I Web:
Add.: 30B, No.58 New Jinqiao Road, Pudong, Shanghai, China
