Yarn bobbin cone winding machine
The machine is characterized with novel design, high coiling speed, large capacity, simple operation, convenient roller change, less wear parts and low energy consumption, with high level of electrome chanical integration, this winder adopts single spindle motor drive frequency converting control low power consumption.
1. Technical features of yarn winder machine:
- High automatic, each worker can look after machine machines;
- Stable products;
- Low management cost and production cost.
2. Application of yarn winder machine:
l Filament yarn.
l Stretch yarn.
l Short fiber.
l Viscose.
l Aramid.
l BCF.
3. Technical specification of yarn rewinding machine:
| No. | Item | Specification |
| 1 | Spindle gauge | 610mm |
| 2 | Number of spindles | 3 spindles/section |
| 3 | Processing speed | 320m/min |
| 4 | Mechanical Speed | 600m/min |
| 5 | Thread guiding distance | 254mm, 300mm |
| 6 | Size: long x wide x height | 1836mm * 750mm * 1570mm |
| 7 | Power of motor | 180W/spindle |
| 8 | Self-stop end down | Electronic sensor |
| 9 | Formation method | Cylindrical |
| 10 | Yarn rack feeding | Optional |
4. Pictures of yarn rewinder machine:
CissCo Machinery is the leading supplier for fiber/yarn twisting machinery in China. More then 95% twisting factories in China are using our twisting machinery.
CissCo Machinery has been persisting in making itself a modernized enterprise based on customers, featuring as " a great erudition, innovativeness, soundiness and cooperatives", following the philosophy of "endless operation in the service of the society" and under the guidance of the policy of the Chinese nation's 5 thousand year-old tradition of "morality-observation, trustworthiness, self-improvement and progress".
CissCo Machinery mainly manufactures TZ serial short-staple, polyester and natural silk two-for-one twisting machine, TZ serial doubling winder. The large roll two-for-one twisting machine and doubling winder series with TZ315 as their repersentatives(10kg content, for 12000D high-denier industrial-purpose silk) are widely used in China for cloth, polyester, cotton textile and natural silk industries. The spindles and textile machinery spare parts developed by our company enjoy a high appreciation of the broad masses of the users for their superior quality and extensive variety.
CissCo Machinery has been trying to enable customers to maximize the benefits with professional serivces such as:
- 24 hours services;
- Overseas installation;
- Free operation training and technology formula transfer;
- Old machine update;
- Spare parts and maintenance with reasonable cost price.
