DISPOSABLE MEDICAL PIPE PRODUCTION MACHINERY
I. About us :
Cissco Machinery Co., LTD has been producing extrusion machinery for more than 10 - years and we have satisfied clients in more than 30 countries throughout the world. We have an excellent reputation for quality , reliability and service, and all our machinery is designed, engineered , and manufactured in China.
II. Disposable medical pipe production machinery
SXG-50/65/75T precision tube extrusion line are the main model of third generation (high speed) series precision pipe line which designed and made by Cissco Machinery Co., LTD, this line is mainly used for producing various kinds of small plastic pipe, such as PA/PU automobile tube, high pressure air and liquid transmission tube, medical catheter, multi-layer composite tube, clean containers straw, and precision communication cable etc. Main feature of this line: high productive efficiency, excellent dimensional stability and high automation degree.
PVC medical pipe extrusion line is specially used for producing various kinds of precision small diameter pipe, for example soft PVC pipe for medical used, PA/PU
precision automobile tube, beverage or clean containers straw and precision communication cable etc.
With professional designed screw suit for high speed SPVC processing and special construction mold, this series line has advantages of high extruding speed, stable continuous production and convenient operation.
III. Disposable medical pipe production machinery FEATURES
1. PVC screw designed by American technology, with bigger L/D and compression ratio, ensures high speed and stable extrusion, meanwhile provides excellent plasticity. Extruder with “ABB” A/C frequency motor and high class “ABB” inverter, which provide accuracy and stable output control, Japan “OMRON” PID intelligent temperature controller, accuracy of temperature control: ±1°C;
2. Main body of cooling tank is made from medical standard stainless steel SUS316 material, which can tolerate long-term oxide etch with 10ppm sodium hypochlorite water. Tank frame with spiral elevating device, can be 3-D moved, trouble free operation; Equipped with stainless steel reservoir and medical standard stainless steel centrifugal pump which can form water circulation loop with outside cooling water supply;
3. Adopt America BETA Laser Mike bi-direction high speed diameter measurement system, which can realize measuring the diameter, ovality and positional value of product on line. Diameter measuring precision can get to ±0.001MM;
4. Puller adopts imported multilayer composite wearable strap (accord with medical sanitary requirements), with high level precision roller driving, stepless speed control;
5. Cutter equips with low inertia aluminum alloy rotating knife arm structure, together with locking device and alcohol cooling system for cutting knife. Driven and controlled by TECO Servo system, which offers high speed and high accuracy cutting action. With Japan Mitsubishi PLC programmable control and SIEMENS human-computer interface, cutter can realize continuous cutting, timing cutting, length counting cutting etc. Cutting length can be set freely, automatic counting.
IV. Disposable medical pipe production machinery COMPONENTS
Item. |
Equipment Name |
Model |
QTY/set |
1 |
Automatic loader |
JL220 |
1 |
2.1 |
Single screw extruder |
BDSJ-50/28 |
1 |
2.2 |
Volumetric type mold |
GM-50 |
1 |
2.3-1 |
Vacuum cooling tank |
ZDX-400-3N |
1 |
2.3-2 |
Cooling tank |
LSX-600-1 |
1 |
2.4 |
Synchronous strap puller |
TKB-600 |
1 |
2.5 |
Automatic rotary cutting and collecting system |
FQ-1T |
1 |
|
|||
v. Disposable medical pipe production machinery SERVICE
- We design, engineer and manufacture and customized the extrusion line.
- Engeniers are
- Choosing the right solution: In plastics manufacturing, process is everything. We carefully evaluate each project's requirements, weigh the options and recommend the best solution for the client.
- Training & Development: we offer extensive start-up assistance, comprehensive training. As well as Engineers for training and installation at our clients factory Support:
- We support the client in all the stages of the project life cycle, as well as the constant spare parts supply in a time efficient manner.
VIII. CONTACT INFORMATION
Loyal Luo, Sales Export & Business Developer
CissCo Machinery Co., Ltd.
Mob.: +86 18817937157 I Office: +86 2138726398 / 99
Email: market02@ I Skype: cisscomachine03 I Web:
Add.: 30B, No.58 New Jinqiao Road, Pudong, Shanghai, China
