Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > GJJ Series High Pressure Vacuum Homogeneous Emulsifying Machine, Vaccum Mixer Homogenizer

GJJ Series High Pressure Vacuum Homogeneous Emulsifying Machine, Vaccum Mixer Homogenizer

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Mixer Type:

Agitator

Product Type:

Other, medicine, cosmetics

Contact Supplier Request Quote Chat Now

Huizhou Pingfang Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port China(Mainland)

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Mixer Type Agitator

Product Type Other, medicine, cosmetics

Application Viscous Fluid

Additional Capabilities Other, emulsifying

Place of Origin Zhejiang, China

Brand Name PF

Model Number GJJ Series

Max. Loading Capacity 1000L-2500L

Voltage 220V/380V

Power(W) 7.5-37kw

Dimension(L*W*H) 1100*676*1065, 1100*676*1085MM

Certification ISO GMP

Warranty One Year, 1 year

After-sales Service Provided Engineers available to service machinery overseas

GJJ Series High Pressure Vacuum Homogeneous Emulsifying Machine, Vaccum Mixer Homogenizer

Product Description

GJJ model series high pressure homogenizer is a kind of new product developed by us according to worldwide up-to-date technology in 1990s. It is applied to the homogenization and emulsillcation of liquid material (liquid-liquid phase or liquid-solid phase) with viscosity below 0.2Pa.x and temperature lower than 80℃. These material sindude dairy food, beverage, cosmetics, medicine and so on.

In time of operation, this product conveys processed material to homogenizing valve in a high pressure way by means of triple plunger reciprocating pump, to make the material acted upon by composite force turbulent flow, positive hole and shearing at the moment when it flows by the small gap between valve disc and valve seat, thus achieving the goal of homogenization and cmulsification.

Technical parameters

Model	Flow(L/H)	Maximum pressure (Mpa)	Rated pressure (Mpa)	Motor Power (KW)	Dimension (L x W x H)
GJJ-1/25	1000	25	20	7.5	1100x676x1065
GJJ-1.5/25	1500	25	20	11	1100x770x1100
GJJ-2/25	2000	25	20	15	1410x850x1900
GJJ-2.5/25	2500	25	20	18.5	1410x850x1190
GJJ-3/25	3000	25	20	22	1410x960x1280
GJJ-4/25	4000	25	20	30	1550x1050x1380
GJJ-5/25	5000	25	20	37	1605x1200x1585
GJJ-6/25	6000	25	20	45	1671x1260x1420
GJJ-8/25	8000	25	20	55	1671x1260x1420
GJJ-1/40	1000	40	35	15	1410x850x1190
GJJ-1.5/40	1500	40	35	22	1410x850x1280
GJJ-2/40	2000	40	35	30	1550x1050x1380
GJJ-2.5/40	2500	40	35	37	1605x1200x1585
