YGF SERIES EASY-FOLDING PLASTIC BOTTLE ORAL-LIQUID FILLING AND SEALING MACHINE
1.Application:
The machine conforms to the "CGMP" requirements, applicable to filling and sealing the new easy-folding plastic bottle. Developed and designed by our company, it is domestic initiative and international leading.
2. Features:
Through a series of special process works of automatic bottle supply, bottom filling, automatic capping, hot melt-type bottom sealing, pneumatic fingers clip sending bottles the machine finishes filling and sealing, being the first choice for oral liquid filling domestic equipment.
The whole machine adopts PLC control, man-machine interface operation, automatic and manual switch control, touch screen Chinese menu monitors, with empty bottles leak, no bottle no filling, leakage bottles and non-cap bottles remove, frequency stepless speed regulation , automatic counting functions.
The machine configured easy-folding plastic bottle is manufactured in clean area, that can reduce the washing, drying and sterilization processes, saving production site area, no broken bottle during loading and transportation.
3.Technical diameters:
| Suitable bottle size | 5-20ml(specially designed easy-folding plastic bottles) |
| Capacity | 160 bottles/min |
| Method of measurement | All metal rotary piston pump |
| Metering accuracy | conforms to the state Pharmacopoeia |
| Method of sealing | bottom auto- heat melt sealing |
| Compressed air consumption | 2m3/min(pressure 0.7Mpa) |
| Total power | 16KW |
| Power supply | 380V,50Hz,3-phase 5-wire system |
| Overall size | 5600×4000×2500(mm) |
Packaging Details: Export-standard and sea-worthy wooden case as following photos.
Delivery time: 15-45 working days normally
Free service: normal spare parts and quick worn parts will be delivered together with the main machine.
Huizhou Pingfang pharmaceutical machinery co. ltd. is a professional manufacturer and supplier for pharmaceutical machinery, pharmaceutical packing material company, who is standing firmly with a good reputation in the industry of China pharmaceutical machinery.
Our company focus on fabricating efficient and technically sound pharmaceutical machines that meets or exceed our customer’ expectations. Our vast product selection caters to numerous industries, worldwide. We are specializing in machinery including, pulverizes, mix, Granulate, tablet press machine, coating machine, soft capsules filling machine, hard capsules filling machine, ampoule filling and sealing machine, oral liquid filling production line, syrup machine, eyes drop filling machine, lyophilized powder production line, injectable vial powder filling production line, Ointment machine, Suppository machine, spray filling machine, pharmaceutical testing and experiment instrument, traditional Chinese medicine machine and packing materials. The packing materials including pharmaceutical PVC, PTP aluminum film, hard aluminum, vial, stopper, aluminum stopper, ampoule, glass, capsule, packing strap of suppository physic. Meanwhile, we can undertake turn key projects for conceptual design, process design, water treatment solutions, clean-room design, etc.
Because we stick to offer the high quality and competitive price to our customer, our machines have been exported many countries of world such as Singapore, Vietnam, Malaysia, Thailand , Bangladesh, USA, Russia, Pakistan, Nigeria, Chile, Germany, Denmark, Bolivia, Peru, Mexico, South Africa, Iran, Argentina, Canada, Australia, India, Kazakhstan, Turkey, Egypt, Brazil, Syria, Yemen and more. In order to offer the best quality, we manufacture our products in accordance with international standards, such as FDA, GMP, CGMP. We also be approved by CE, ISO certificate, too.
Our Customers:
Our Certificates:
Q1: What information should I let you know if I want to get quotation?
A: -the size of products (Length*Width*Height)
-the material
-if it is possible, please provide us the pictures or the design drawings, our designer will analyze your samples and give you exact details.
Q2: Is there MOQ for our machine?
A: 1 set is acceptable. Of course, if you order more, it will be fine and its price will be more competitive.
Q3: Do you have manual or operation video for us to know more about the machine?
A: Yes, of course. Please email us and ask for it. We will send you soon.
Q4: When can I get the price?
A: We usually quote within 24 hours after getting your inquiry. If you are urgent to get the price, please call us or tell us in your email. We will regard your inquiry priority.
Q5: How does your factory regard quality control?
A: Quality is priority. It’s the basement of company’s development. From the beginning of opening company, we especially focus on quality job. Our pharmaceutical equipment have passed the GMP model patents and invention patents issued by State Patent Office of China.
Pre-sale:
According to customer’s needs guide customers t configure the most appropriate device models. According to customer’s special requirements and working site provide list of equipment, equipment layout.
Dur-sale:
Inspect the product seriously before out of the factory. Invite customer for commissioning in the spot and raising the objection. Organize to delivery according to the contract.
After-sale:
Company can send technical data for guiding to install and debug the machine. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price. We also can provide 24-hour telephone or message service.
