(FG-KFG2-B) KFG Series Automatic Filling and Capping Machine for Hot Selling

(FG-KFG2-B) KFG Series Automatic Filling and Capping Machine for Hot Selling photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Food, Medical, Other, Chemical, Food, Medical, filling machine
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port China(Mainland)
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Chemical, Food, Medical, Other, Chemical, Food, Medical, filling machine
Packaging Type Case
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 380V
Power 1.5kw
Place of Origin Shanghai, China
Brand Name PF
Model Number KFG2B
Dimension(L*W*H) 2620*1000 *1750(mm)
Weight 480kg
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas





 (FG-KFG2-B) KFG series automatic filling and capping machine for hot selling







1.  Application:

Fg-kfg2-b type powder filling machine is a powder filling and capping machine (monoblock) which is researched by our company according to the special requirements from customers. It uses 3 guaduators to conduct filling, stoppering and capping 3 process.This machine is suitable for pharmaceutical companies which has small production capacity and small room size.



2. Features:

Monoblock machine equips with filling and capping, suitable for customers with small production capacity and small scale.

Different type of filling auger meets requirements of powder with different fluidity

Can adjust the filling dosage without stopping the machine

Adopt 3 knife flexible capping head, bottle breakage ratio is low.

Touch panel control can set the filling dosage without stopping the machine

Speed controlled by inverter

Falling bottle auto reject; no bottle, no filling; no stoppers, auto stops; insufficient stoppers alarm

Auto counting function

CE certified, standard electric installation, safety guarantee on operation

Auto stop filling when filling auger touches filling nozzle and alarms

Easy to change the change part, filling dosage adjustable

Optional acrylic glass hood, laminar flow, sealed air outlet device

The whole machine is designed according to GMP requirements.



3. Technical Parameters:

Suitable bottle range

7~250ml tubular or molded vial((Change the proper change part))

Power supply

380V 50Hz

Power consumption

1.5kw

Filling error

≤2%

Auto stoppering ratio

≥99.5%

Qualified capping ratio

≥99.7%

Speed contro

Speed control by inverter

Single machine noise

≤70dB

Vacuum degree

-6×10-2mpa     14m3/h

Weight

480kg

Dimension

2620×1000 ×1750(mm)









4.Factory shows:



(FG-KFG2-B) KFG series automatic filling and capping machine for hot selling







5. Other filling machines:

 (FG-KFG2-B) KFG series automatic filling and capping machine for hot selling(FG-KFG2-B) KFG series automatic filling and capping machine for hot selling







 6. Product samples:



(FG-KFG2-B) KFG series automatic filling and capping machine for hot selling





    (FG-KFG2-B) KFG series automatic filling and capping machine for hot selling





7.Our customers:



(FG-KFG2-B) KFG series automatic filling and capping machine for hot selling



(FG-KFG2-B) KFG series automatic filling and capping machine for hot selling







8. Certificates:



(FG-KFG2-B) KFG series automatic filling and capping machine for hot selling(FG-KFG2-B) KFG series automatic filling and capping machine for hot selling(FG-KFG2-B) KFG series automatic filling and capping machine for hot selling
