NJP-2000C Automatic pill Capsule powder Filling Machine
I. Introduction:
It is a new type capsule filling machine that designed for small batch production enterprise, meet GMP requirement. And it is easy to operate by PLC control. It can finish the following work at same time: capsule feeding, capsule separating, power filling, capsule rejecting, capsule locking, finished capsule discharge ect. It adopts one camber roller gear cam index, running is steady and the noise is lower. It has the features of hole plate type and five times filling ensure the high filling precision.
II. Technical Parameters:
Equipment Model |
NJP-2000C |
|
Technical Parameter |
Machine weight |
1450kg |
Overall dimension |
1100 × 1200 × (1950+150) mm |
|
Motor power |
3.37kw + 3kw (Dust Collector) |
|
Power supply |
3 phase, AC 380V, 50Hz |
|
Max. Output |
120,000capsules/hr |
|
Capsule size |
00#~5# and safety capsule A~E |
|
Capsule using rate |
≥ 99.5% |
|
Noise index |
≤ 75dBA |
|
Dosage difference |
≤ ±3% (under more than 300mg dosing and 40~80 mesh after granulation) |
|
|
Compress air (die segment-clearing) |
Gas displacement 0.06m3/min Pressure 0.3Mpa |
|
Water supply |
Water cycle pump compound water tank, or meet water source |
|
Vacuum degree |
-0.02~-0.06MPa |
|
Water volume |
250L/hour |
|
Enter pipe inner-diameter |
20mm |
|
Waterspout inner-diameter |
27mm |
|
Working temperature |
21℃± 3℃ |
|
Working relative humidity |
40~55% |
|
Exhaust capacity |
300m3/h |
|
Special function |
Granule and powder mixed filing; Powder collector function (Another pipeline collect powder in the filling port, needn’t disinfect and accede to hopper directly) |
|
Control system |
Frequency conversion adjust stepless, PLC control |
|
Material |
Spare part contact with medicine adopt superior S.S 304 |
|
Criterion |
Conform to GMP completely |
|
Packaging Details: Export-standard and sea-worthy wooden case as following photos.
Delivery time: 15-45 working days normally
Free service: normal spare parts and quick worn parts will be delivered together with the main machine.
