Introduction
It is controlled by computer to complete Enzyme Linked Immunosorbent Assay (ELISA).
96 well microplate is available to analyze and report.
The application can be categorized into clinical diagnostic laboratories, food safety inspection and animal and plant quarantine.
Features
-Large LCD display, with touch screen.
-8-channel optical fibers system enables rapid reading for 96-well plate.
-Calculation Method: Factor Method, Linear Regress, Quadratic Curve, Point to Point, Exponential Function, Logarithmic Function, Cubic Spline Curve.
-96-well plate, with PC software. It can complete multiple tests in one single plate.
-Test method: ABS, Qualitative, Level, Quantitative, Kinetic Quantitative.
-User-friendly operation software (Optional): With PC software, it can jj
input/ inquire patient information, input/inquire test results,
print patients report,
automatically save the Quality control data,
build quality control chart,
set microplate parameter,
conduct Qualitative and quantitative detection.
We also provide the scientific research professional software, test data can be exported in MS Excel for further analysis.
Main Specifications
Display | 240×128 LCD ( touch Screen ) |
Interface | RS232 9 needle |
Suitable microplate type | 96 wells, Flat bottom, U bottom, V bottom |
Shake | 3 kinds of intensity (High, Medium, Low) |
Memory | 200 analysis programs, 1000 testing result |
Light Source | 12V,20W Halogen |
Wavelength range | 400nm to 750nm |
Optical sensor | 8 photodiode |
Standard filters | 4 optical filter, 405,450,492,630nm |
Reading speed | 6 sec in single wavelength. 10s in double wavelength |
Absorbance range | 0.000 to 3.500 ABS |
Resolution | 0.001 ABS |
Absorbance stability | ±0.003 Abs |
Accuracy | ΔA≤±0.01 Abs(0≤A<1.0 Abs); ≤2.5%(1.0 Abs≤A≤2.5 Abs); |
Sensitivity | ≥0.01 |
Repeatability difference | ≤0.2% (0≤A≤1.5 Abs); ≤1.0% (1.5 Abs <A≤2.5 Abs); |
Channel difference | ≤0.02 Abs |
Linearity | ≥0.999 |
Internal printer | 58mm thermal printer |
Voltage | AC 220V, 50Hz |
Power | 90 VA |
Size | 318*286*168mm |
Weight | 6.5Kg |
Working temperature | 10℃—30℃ |
Working humidity | ≤ 85% |
Storage temperature | 0℃—55℃ |
Storage humidity | ≤ 95% |
Spare part list | |
Mainframe | 1 |
Power adapter | 1 |
Fuse | 2 |
Thermal printer paper | 1 |
Keyboard | 1 |
Operation manual (English language) | 1 |
QC report | 1 |
Warranty card(one year) | 1 |
