DW-SM800 Full-Automatic Micro-Plate Reader
Features
-Large color LCD display, with touch screen.
-Long flexibility and reliability
-Excellent optical system
-User-friendly software
New DW-SM800 Microplate reader with 18.5 inch large color LCD display, touch screen, 96 hole Visualize cloth plate, with touch PC software.It can achieve multiple tests in the single plate.
It is controlled by computer to complete Enzyme Linked Immunosorbent Assay (ELISA). Read 96 well microplate, analyse and report, which is widely used in clinical diagnostic laboratories, centers for disease control and prevention, animal and plant quarantine, animal husbandry and veterinary epidemic prevention stations, biotechnological industries, food industries, environmental science, agricultural scientific research and other academic organizations. It provides the reliable flexibility.
-Optical system of Microplate Reader includes one high-quality halogen lamp, 8 channel optical fibers, detectors and filters, ensure that instruments long-term stable operation, accurate measured results and free maintenance.
-Calculation modes include end point, kinetic and so on, flexible critical value of qualitative calculation
-User-friendly operation software (Optional): The software is a Windows based interface specifically for hospital laboratory and blood bank design, input/query patient data, input /query results, print patient comprehensive report for quality control chart, set the enzyme parameters for the qualitative and quantitative detection.
Main Specifications
Display | 18.5 inch LCD ( Touch Panel ) |
Interface | RS232 9 needles |
Suitable Microplate Type | 96 wells, Flat bottom, U bottom, V bottom |
Shake | 3 kinds of intensity(High, Medium, Low) |
Memory | Large database can store huge amounts of data |
Light Source | 12V,20W Halogen |
Wavelength range | 400nm to 750nm |
Optical sensor | 8 photodiode |
Standard filters | Interference filter 405,450,492,630nm |
Reading speed | Single wavelength 6 sec, Double wavelength 10 sec. |
Absorbance range | 0.000 to 3.500 ABS |
Resolution | 0.001 ABS |
Absorbance stability | ±0.003 Abs |
Accuracy | ΔA≤±0.01Abs(0≤A<1.0 Abs); ≤2.5%(1.0 Abs≤A≤2.5 Abs); |
Sensitivity | ≥0.01 Abs |
Repeatability | ≤0.2%(0≤A≤1.5 Abs); ≤1.0%(1.5 Abs <A≤2.5 Abs); |
Channel difference | ≤0.02 Abs |
Linearity | ≥0.999 |
Voltage | AC 220V, 50Hz |
Power | 90 VA |
Size | 420*260*270mm |
Weight | 15Kg |
Working temperature | 10℃—30℃ |
Working humidity | ≤ 85% |
Storage temperature | 0℃—55℃ |
Storage humidity | ≤ 95% |
